Converting Tycho Projects to maven-bundle-plugin, Initial Phase

Aug 22, 2019 3:27 PM

Tags: maven osgi tycho
  1. Developing an Open/WebSphere Liberty UserRegistry with Tycho
  2. Developing Open Liberty Features, Part 2
  3. Converting Tycho Projects to maven-bundle-plugin, Initial Phase

To date, Tycho has been my tool of choice for developing Domino-targeted Maven projects. However, it's not without protest.. Unlike most Maven plugins, Tycho inserts itself at the very start of the build process and takes over dependency management. Purely in Maven, you can use normal Maven dependencies, but only so long as you're pointing to a dependency that already has OSGi metadata (which, fortunately, most do), and only then to satisfy a Require-Bundle or Import-Package that also has to be present. This gets more annoying, though, when dealing with Eclipse, which removes the notion of Maven dependencies entirely when using Tycho and forces you to jump through hoops to do what you want. And, as a final kicker, Tycho's p2 repository support is completely broken in the latest release version of Maven.

So why do I keep using it, anyway?

Well, it brings a couple major benefits that are of particular importance for Domino:

  • It can use p2 repositories for dependencies. This matters because the XPages runtime plugins are not (yet?) available as normal Maven dependencies. Years back, IBM [provided a "Build Management" update site](https://openntf.org/main.nsf/project.xsp?r=project/IBM Domino Update Site for Build Management), which is helpful, but it's still an Eclipse-style p2 repository, not a Maven repository. Tycho can use p2 repositories natively, though, just as Eclipse does.
  • It constructs a true Equinox environment. This matters both when compiling your project and when running automated tests. The environment created by Tycho is the same Equinox OSGi runtime that Domino uses, and so it supports the same styles of bundle resolution and extensions that you get in Domino. Without this happening during the build, you lose some assurance that things at runtime will match your expectations.
  • It spawns tests in a separate process. This is a little esoteric, but it matters because launching a Notes environment on a non-Windows platform more-or-less requires setting up environment variables for the Notes/Domino directory and others, and these variables are not successfully set when using the normal maven-surefire-plugin runtime. This means that reliably running tests requires setting up the environment ahead of time, which is fiddlier and less automated.
  • It can generate new- and old-style Eclipse Update Sites. To be used in Designer and NSF-based Update Sites, an OSGi project has to be packaged up into a p2 repository along with an old-style "site.xml" file. Tycho can generate these (and can be assisted with "site.xml" when using the newer style), and it can also auto-generate source bundles, features, and repositories.

Alternatives and Workarounds

Some of the "hard" requirements for Tycho can be at least worked around.

Years ago, I wrote a Ruby script that would take a p2 site like IBM's or one generated from a newer version and "Mavenize" it by creating artifact information based on each bundle's OSGi manifest. I since converted it to Java and included it in Darwino's Studio plugins, and yesterday added it to the generate-domino-update-site Maven plugin. Using that lets you declare dependencies on any of the bundles or embedded JARs in a normal Maven project:

1
2
3
4
5
6
7
        <dependency>
            <groupId>com.ibm.xsp</groupId>
            <artifactId>com.ibm.notes.java.api.win32.linux</artifactId>
            <version>[10.0.0,)</version>
            <classifier>Notes</classifier>
            <scope>provided</scope>
        </dependency>

This isn't perfect, since it's neither standardized nor generally available (go vote for the aha idea!), but at least it's reproducible and can be something of a de-facto standard if used enough.

Then there's the matter of generating appropriate OSGi metadata. Outside of the Tycho-using world, the main way that generating this is via a tool called bnd and its related tools. bnd is kind of a parallel world and there's even an alternate tooling set for Eclipse instead of the default PDE. There are a couple ways to use bnd in a Maven build, but the one I'm familiar with to date is the maven-bundle-plugin. I've used this with Darwino to incidentally create OSGi metadata for the otherwise non-OSGi core modules, and I suspect that it gets used heavily this way. It's more powerful than that, though, and is a nice wrapper for bnd under the hood, supporting Declarative Services annotations and all the other OSGi goodies. In my case, I used it to generate the MANIFEST.MF with most of the defaults, but then added in some specifics to play nice in my Domino Equinox target.

I suspect that these bnd-based tools can also be a route to solving my automated-testing woes. For the Open Liberty Runtime project, I don't have to worry about that, since it's so dependent on running in actual Domino that the return-on-investment for setting up JUnit tests wouldn't be worth it. However, I recall seeing some Maven testing plugin that let you spawn an OSGi environment of your choice, and I think that something like that may be able to replace Tycho for me there.

Since p2 repositories/update sites are entirely an Eclipse-ism, most OSGi tooling doesn't care about them. That's where p2-maven-plugin comes in. Not only will it allow you to create p2 repositories, but it lets you define features in the configuration, meaning they don't have to be separate modules like in Tycho. And not only that, but it will also auto-OSGi-ify any Maven dependencies you bring in if they don't already have OSGi bundle information. It also lets you override existing bundle data on the fly if needed, such as if the dependencies and imports conflict with something on Domino.

Eclipse Friendliness

Since I still use Eclipse to develop these projects, I want to be able to make use of the XPages SDK's ability to run Domino's HTTP stack pointed at my active workspace. For that to work, I need to be able to get Eclipse to recognize my projects as functional PDE-compatible bundles even if I'm not using PDE for them. Fortunately, that process isn't difficult: once I set the location for MANIFEST.MF to be in "META-INF" in the project root, maven-bundle-plugin started generating the files there instead of within "target", and Eclipse started working with the projects as OSGi bundles. The only thing left to do then was to gitignore the generated files, since they don't need to be checked into source control anymore.

Future Improvements

The big thing that is still an open problem is dealing with testing. I have some ideas for taking a swing at it, but for now it's the main thing preventing me from doing this for all of my Tycho projects.

Beyond that, I want to look a bit into bnd-maven-plugin. This diverges from maven-bundle-plugin in that it's geared towards using bnd configuration files directly. During the build process, I think the results would be the same, since maven-bundle-plugin can already pass through whatever configuration I want, but it would be a better match for the Eclipse bndtools tooling. Additionally, externalizing the bnd config files would mean they'd be the same if I decided to switch to Gradle, as Open Liberty uses.

Finally, and specific to this Open Liberty project, I may want to consider using bnd to generate Liberty Feature manifests, as it itself does. These features are implemented as OSGi "subsystems" packaged .esa files. Currently, I'm using esa-maven-plugin to generate their specialized manifests, but I've already hit some limitations in the area of cross-feature dependencies. Apparently, bnd takes some wrangling to suit this, but is worth it. I'll consider that one a "stretch goal", though.

For now, I'm pretty pleased with the new setup. The projects still work on Domino, I can run them on there from the workspace, I was able to eliminate the p2 feature projects outright, and now I don't have to worry about packaging up a dependencies site just to have something to point at in Eclipse. Heck, I can even use Visual Studio Code now! It's pretty nice.

Developing Open Liberty Features, Part 2

Aug 18, 2019 9:14 AM

  1. Developing an Open/WebSphere Liberty UserRegistry with Tycho
  2. Developing Open Liberty Features, Part 2
  3. Converting Tycho Projects to maven-bundle-plugin, Initial Phase

In my earlier post, I went over the tack I took when developing a couple extension features for Open Liberty, and specifically the way I came at it with Tycho.

Shortly after I posted that, Alasdair Nottingham, the project lead for Open Liberty, dropped me a line to mention how programmatic service registration isn't preferred, and instead the idiomatic way is to use Declarative Services. I had encountered DS while fumbling my way through to getting these things working, but I had run into some bit of trouble or another, and I ended up settling on what I got working and not revisiting it.

Concepts

This was a perfect opportunity to go back and do things the right way, though, so I set out to do that this morning. In my initial reading up, I ran across a blog post from the always-helpful Vogella Blog that talks about coming at OSGi DS from essentially the same perspective I have: namely, having been used to Equinox and the Eclipse plugin/extension mechanism. As it turns out, when it comes to generic OSGi, Equinox can kind of poison your brain. The whole term "plug-in" instead of "bundle" comes from earlier Eclipse; "features", "update sites", and all of p2 are entirely Equinox-specific; and the "plugin.xml" extension mechanism is of a similar vintage. However, unlike some other vestiges that were tossed aside, "plugin.xml" is still in active use.

At its core, the Declarative Services system is generally similar to that route, in that you write classes to implement a given interface and then declare that your bundle provides that using XML files. The specifics are different - DS is more type-safe and it uses individual XML files in the "OSGI-INF" directory for each service - but the concept is similar. DS also has an annotation-based mechanism for this, which allows you to annotate your service classes directly and not worry about maintaining XML files. It's something of a compiler trick: the XML files still exist, but your tooling of choice (PDE, bnd, etc.) will generate the files based on your annotations. It took a bit for Eclipse to get on board with this, but, as of Neon, you can enable this processing in the preferences.

Implementation

Fortunately for me, my needs are simple enough that making the change was pretty straightforward. The first step was to delete the Activator class outright, as I won't need it for this. The second was to add an optional import for the org.osgi.service.component.annotations package in my Liberty extension bundle. I suspect that this is a bit of a PDE-ism: the annotations aren't even retained at runtime (and the package isn't present in the Liberty server), but this is the only mechanism Eclipse has to add a dependency for a plug-in project.

The annotation for the user registry was as straightforward as can be, needing a single line in this heavily-clipped version of the class:

1
2
3
@Component(service=UserRegistry.class, configurationPid="dominoUserRegistry")
public class DominoUserRegistry implements UserRegistry {
}

With that, Eclipse started generating the associated XML file for me, and the registry showed up at runtime just as it had before.

The TrustAssociationInterceptor was slightly more complicated because it had some extra initialization properties set, in particular the one to mark it as executing before normal SSO. This was a little tricky in two ways: Java annotations don't have any mechanism for specifying a literal Map for properties, and the before-SSO property is a boolean, but I could only write a string. It turned out that the property, uh, property on the annotation has a little mini-DSL where you can mark a property with its type. The result was:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
@Component(
	service=TrustAssociationInterceptor.class,
	configurationPid=DominoTAI.CONFIG_PID,
	property={
		"invokeBeforeSSO:Boolean=true",
		"id=org.openntf.openliberty.wlp.userregistry.DominoTAI"
	}
)
public class DominoTAI implements TrustAssociationInterceptor {
}

Further Features

This is proving to be a pretty fun side project within a side project, and I think I'll take a crack at developing some more features when I have a chance. In particular, I'd like to try developing some API-contribution features so that they can be deployed to the server once and then used by web apps without having to package them (similar in concept to XPages Libraries). This is how Liberty implements its Jakarta EE specifications, and I could see making some extra ones. That's also exactly what CrossWorlds does, and so I imagine I'll crib a bunch of that work.

Developing an Open/WebSphere Liberty UserRegistry with Tycho

Aug 16, 2019 3:08 PM

  1. Developing an Open/WebSphere Liberty UserRegistry with Tycho
  2. Developing Open Liberty Features, Part 2
  3. Converting Tycho Projects to maven-bundle-plugin, Initial Phase

In my last post, I put something of a stick in the ground and announced a multi-blog-post project to discuss the process of making an XPages app portable for the future. In true season-cliffhanger fashion, though, I'm not going to start that immediately, but instead have a one-off entry about something almost entirely unrelated.

Specifically, I'm going to talk about developing a custom UserRegistry and TrustAssociationInterceptor for Open Liberty/WebSphere Liberty. IBM provides documentation for this process, and it's alright enough, but I had to learn some specific things coming at it from a Domino perspective.

What These Services Are

Before I get in to the specifics, it's worth discussing what specifically these services are, especially TrustAssociationInterceptor with its ominous-sounding name.

A UserRegistry class is a mechanism to provide a Liberty server with authentication and user info services. Liberty has a couple of these built-in, and the prototypical ones are the basic and LDAP registries. Essentially, these do the job of the Directory and Directory Assistance on Domino.

A TrustAssociationInterceptor class is related. What it does is take an incoming HTTP request and look for any credentials it understands. If present, it tells Liberty that the request can be considered authenticated for a given user name. The classic mechanisms for this are HTTP Basic and form-cookie authentication, but this can also cover mechanisms like OAuth. In Domino, this maps to the built-in authentication mechanisms and, more particularly, to DSAPI filters.

How I Used Them

My desire to implement these developed when I was working on the Domino Open Liberty Runtime. I wanted to allow Liberty to use the containing Domino server as a user registry without having to enable LDAP and, as a stretch goal, I wanted to have some sort of implicit SSO without having to configure LTPA.

So I ended up devising something of an ad-hoc directory API exposed as a servlet on Domino, which Liberty could use to make the needed queries. To pair with that, I wrote a TrustAssociationInterceptor implementation that looks for Domino auth cookies in incoming requests, make a call to a small servlet with that cookie, and grabs the associated username. That provides only one-way SSO, but that's good enough for now.

The Easy Part

The good part was that my assumption that my comfort with Tycho going in would help was generally correct. Since the final output I wanted was a bundle, I was able to just add it to my project structure like any other, and work with it in Eclipse's PDE normally. Tycho and PDE didn't necessarily help much - I still had to track down the Liberty API plugins and make a local update site out of them, but that was old hat by this point.

What Made Development Weird

I went into the project in high spirits: the interfaces required weren't bad, and Liberty uses OSGi internally. I figured that, with my years of OSGi experience, this would be a piece of cake.

And, admittedly, it kind of was. The core concepts are the same: building with Tycho, bundle activators, MANIFEST.MF, and all that. However, Liberty's use of OSGi is, I believe, much more modern than Domino's, and certainly much less focused on Equinox specifically.

For one, though Liberty is indeed OSGi-based, it doesn't use Maven Tycho for its build process. Instead, it uses Gradle and the often-friendlier bnd tooling to handle its OSGi composition. That's not too huge of a difference, and the build process doesn't really affect the final built feature. The full differences are a whole big topic on their own, but the way they shake out for this purpose is essentially a difference in philosophy, and the different build mechanism was something of a herald of the downstream distinctions.

One big way this shows is in service registration. Coming from an Eclipse heritage, Equinox-based apps tend to use "plugin.xml" to register services, Liberty (and most others, I assume) favors programmatic registration of services inside the bundle activator. While this does indeed work on Equinox (including on Domino), this was the first time I'd encountered it, and it took some getting used to.

The other oddity was how you encapsulate your bundle as a feature in Liberty parlance. Liberty uses the term "feature" to refer to individual components that make up the server, and which you can configure in the "server.xml" file. These are declared using files similar to MANIFEST.MF with specialized headers to declare the name of the feature, the bundles that make it up, and any APIs it provides to the server and apps. In my case, I wrote a generic mechanism to deploy these features when a server is established, which writes the manifest files to the server's feature directory. Once they're deployed, they become available to the server as a feature with the "usr" prefix, like "usr:dominoUserRegistry-1.0" for my case.

In The Future

I have some ideas for additional features I'd like to develop - providing implicit APIs for Darwino and Jakarta NoSQL/JNoSQL would be handy, for example. This way went pretty smoothly, but I'll probably develop non-Domino ones using either Gradle or Maven with the maven-bundle-plugin. Either way, it ended up fairly pleasant once I discarded my old assumptions, and it's another good entry in the "pros" column for Liberty.

AbstractCompiledPage, Missing Plugins, and MANIFEST.MF in FP10 and V10

Oct 19, 2018 11:48 AM

Since 9.0.1 FP 10, and including V10 because it's largely identical for this purpose, I've encountered and seen others encountering a couple strange problems with compiling XPages projects. This is a perfect opporunity for me to spin a tale about the undergirding frameworks, but I'll start out with the immediate symptoms and their fixes.

The Symptoms

There are three broad categories of problems I've seen:

  • "AbstractCompiledPage cannot be resolved to a type"
  • Missing third-party XPages libraries, such as ODA, resulting in messages like "The import org.openntf cannot be resolved"
  • Complaints about MANIFEST.MF, like "MANIFEST.MF has no main section" and others

The first two are usually directly related and have the same fix, while the second can also be caused by some other sources, and the last one is entirely distinct.

Fix #1: The Target Platform

For the first two are based on problems in the active Target Platform, namely one or both of the standard platform components go missing. The upshot is that you want your Target Platform preferences to look something like this:

Working Target Platform

There should be a selected platform (the name doesn't matter, but "Running Platform" is the default name) with entries at least for ${eclipse_home} and for a directory inside your Notes data dir, here C:\Notes\Data\workspace\applications\eclipse. If they're missing, modify an existing platform or create a new one and add an "Installation"-type entry for ${eclipse_home} and a "Directory"-type one for the eclipse directory within your data dir.

Fix #2: Broken Plugins, Particularly ODA

Though V10 didn't change much when it comes to XPages, there are a few small differences. One in particular bit ODA: we had a dependency on the com.ibm.domino.commons plugin, which was in the standard Notes environment previously but is not as of V10 (though it's still present on the server). We fixed that one in the V10 release, and so you should update your ODA version if you hit this trouble. I don't think I've seen other plugins with this issue in the V10 transition, but it's a possibility if Fix #1 doesn't do it.

Fix #3: MANIFEST.MF

This one barely qualifies as a "fix", but it worked for me: if you see Designer complaining about MANIFEST.MF, you can usually beat it into submission by cleaning/rebuilding the project in question. The trouble is that Designer is, for some reason, skipping a step of the XPages compilation process, and cleaning usually kicks it into gear.

I've also seen others have success by deleting the error entry in the Errors view (which is actually a thing that you can do) and never seeing it again. I suspect that the real fix here is the same as above: during the next build, Designer creates the file properly and it goes away on its own.

The Causes

So what are the sources of these problems? The root reason is that Designer is a sprawling mountain of code, built on ancient frameworks and maintained by a diminished development team, but the immediate causes have to do with OSGi.

The first type of trouble - the target platform - most likely has to do with a change in the way Eclipse manages target platforms (look at the same prefs screen in 9.0.1 stock and you'll see it's quite different), and I suspect that there's a bug in the code that migrates between the two formats, possibly due to the dramatic age difference in the underlying Eclipse versions.

The second type of trouble - the MANIFEST.MF - is due to a behind-the-scenes switch in how Designer (and maybe the server) handles dependencies in XPages projects.

Target Platforms

The mechanism that OSGi projects - such as XPages applications - use for determining their dependencies at build time is the notion of a "Target Platform". The "target" refers to the notion that this is the platform that is expected to be available at runtime for what you're building - loosely equivalent to a basic Java classpath. An OSGi project is checked against this Target Platform to determine which classes are available based on their bundle names and versions.

This is distinct from the related concept of a "Running Platform". Designer, being based on Eclipse, is itself built on and runs using OSGi. Internally, it uses the same mechanisms that an XPages application does to determine what plugins it knows about and what services those plugins provide.

This distinction has historically been hidden from XPages developers due to the way the default Target Platform is set up, pointing at the same Running Platform it's using. So Designer itself has the core XPages plugins running, and it also exposes them to XPages applications as the Target. Similarly, the way we install XPages Libraries like ODA is to install them outright into the Designer Running Platform. This allows Designer to know about the library service provided, which it uses to populate the list of available plugins in the Xsp Properties editors.

However, as our trouble demonstrates, they're not inherently the same thing. In standalone OSGi development in Eclipse, it's often useful to have a Target Platform distinct from the Running Platform - such as the XPages environment for plugins - to ensure that you only depend on plugins that will be available at runtime. But when the two diverge in Designer, you end up with situations like this, where Designer-the-application knows about the XPages runtime and plugins and constructs an XPages project and translates XSP to Java using them, but then the compilation process with its empty Target Platform has no idea how to actually compile the generated code.

MANIFEST.MF

I've mentioned that an OSGi project "determines its dependencies" out of the Target Platform, but didn't mention the way it does that. The specific mechanism has changed over time (which is the source of our trouble), but the idea is that, in addition to the Java classes and resources, an OSGi bundle (or plugin) has a file that declares the names of the plugins it needs, including potentially a version range. So, for example, a plugin might say "I need org.apache.httpcomponents.httpclient at least version 4.5, but not 5.0 or higher". The compiler uses the Target Platform to find a matching plugin to compile the code, and the runtime environment (Domino in our case) does the same with its Running Platform when loading.

(Side note: you can also specify Java packages to include from any plugin instead of specific plugin names, but Designer does not do that, so it's not important for this purpose.)

(Other side note: this distinction comes, I believe, from Eclipse's switch from its own mechanism to OSGi in its 3.0 release, but I use "OSGi" to cover the general concept here.)

The old way to do this was in a file called "plugin.xml". If you look inside any XPages application in Package Explorer, you'll see this file and the contents will look something like this:

<?xml version="1.0" encoding="UTF-8"?>
<?eclipse version="3.0"?>
<plugin class="plugin.Activator"
  id="Galatea2dVCC_2fIKSG_dev5csyncagent_nsf" name="Domino Designer"
  provider="TODO" version="1.0.0">
  <requires>
    <!--AUTOGEN-START-BUILDER: Automatically generated by null. Do not modify.-->
    <import plugin="org.eclipse.ui"/>
    <import plugin="org.eclipse.core.runtime"/>
    <import optional="true" plugin="com.ibm.commons"/>
    <import optional="true" plugin="com.ibm.commons.xml"/>
    <import optional="true" plugin="com.ibm.commons.vfs"/>
    <import optional="true" plugin="com.ibm.jscript"/>
    <import optional="true" plugin="com.ibm.designer.runtime.directory"/>
    <import optional="true" plugin="com.ibm.designer.runtime"/>
    <import optional="true" plugin="com.ibm.xsp.core"/>
    <import optional="true" plugin="com.ibm.xsp.extsn"/>
    <import optional="true" plugin="com.ibm.xsp.designer"/>
    <import optional="true" plugin="com.ibm.xsp.domino"/>
    <import optional="true" plugin="com.ibm.notes.java.api"/>
    <import optional="true" plugin="com.ibm.xsp.rcp"/>
    <import optional="true" plugin="org.openntf.domino.xsp"/>
    <!--AUTOGEN-END-BUILDER: End of automatically generated section-->
  </requires>
</plugin>

You can see it here declaring a name for the pseudo-plugin that "is" the XPages application (oddly, "Domino Designer"), a couple other metadata bits, and, most importantly, the list of required plugins. This is the list that Designer historically (and maybe still; it's not clear) uses to populate the "Plug-in Dependencies" section in the Package Explorer view. It trawls through the Target Platform, finds a matching version of each of the named plugins (the latest version, since these have no specified ranges), adds it to the list, and recursively does the same for any re-exported dependencies of those plugins. "Re-exported" isn't exposed here as a concept, but it is a distinction in normal OSGi plugins.

Designer derives its starting points here from implicit required libraries in XPages applications (all those "org.eclipse" and "com.ibm" ones above) as well as through the special mechanism of XspLibrary extension contributions from plugins installed in the Running Platform. This is why a plugin like ODA has to be installed in Designer itself: in the runtime, it asks its plugins if they have any XspLibrary classes and uses those to determine the third-party plugin to load. Here, ODA declares that its library needs org.openntf.domino.xsp, so Designer adds that and its re-exported dependencies to the Plug-in Dependencies group.

With its switch to OSGi in the 3.x series circa 2005, most of the functionality of plugin.xml moved to a file called "META-INF/MANIFEST.MF". This starkly-named file is a standard part of Java, and OSGi extends it to include bundle/plugin metadata and dependency declarations. As of 9.0.1 FP10, Designer also generates one of these (or is supposed to) when assembling the XPages project. For the same project, it looks like this:

Manifest-Version: 1.0
Bundle-ManifestVersion: 2
Bundle-Name: Domino Designer
Bundle-SymbolicName: Galatea2dVCC_2fIKSG_dev5csyncagent_nsf;singleton:=true
Bundle-Version: 1.0.0
Bundle-Vendor: TODO
Require-Bundle: org.eclipse.ui,
  org.eclipse.core.runtime,
  com.ibm.commons,
  com.ibm.commons.xml,
  com.ibm.commons.vfs,
  com.ibm.jscript,
  com.ibm.designer.runtime.directory,
  com.ibm.designer.runtime,
  com.ibm.xsp.core,
  com.ibm.xsp.extsn,
  com.ibm.xsp.designer,
  com.ibm.xsp.domino,
  com.ibm.notes.java.api,
  com.ibm.xsp.rcp,
  org.openntf.domino.xsp
Eclipse-LazyStart: false

You can see much of the same information (though oddly not the Activator class) here, switched to the new format. This matches what you'll work with in normal OSGi plugins. For Eclipse/Equinox-targeted plugins, like XPages libraries, plugin.xml still exists, but it's reduced to just declaring extension points and contributions, and no longer includes dependency or name information.

Eclipse had moved to full OSGi by the time of Designer's pre-FP10 basis (2008's 3.4 Ganymede), but XPages's history goes back further, so I guess that the old-style Eclipse plugin.xml route is a relic of that. For a good while, Eclipse worked with the older-style plugins without batting an eye. FP10 brought a move to 2016's Eclipse 4.6 Neon, though, and I'm guessing that Eclipse dropped the backwards compatibility somewhere in the intervening eight years, so the XPages build process had to be adapted to generate both the older plugin.xml files for backwards compatibility as well as the newer MANIFEST.MF files.

I can't tell what the cause is, but, sometimes, Designer fails to populate the contents of this file. It might have something to do with the order of the builders in the internal Eclipse project file or some inner exception that manifests as an incomplete build. Regardless, doing a project clean and usually jogs Designer into doing its job.

Conclusion

The mix of layering a virtual Eclipse project over an NSF, the intricacies of OSGi, and IBM's general desire to insulate XPages developers from the black magic behind the scenes leads to any number of opportunities for bugs like these to crop up. Honestly, it's impressive that the whole things holds together as well as it does. Even though it doesn't seem like it to look at the user-visible changes, the framework changes in FP10 were massive, and it's not at all surprising that things like this would crop up. It's just a little unfortunate that the fixes are in no way obvious unless you've been stewing in this stuff for years.

Dealing with OSGi Fragments in Tycho and Designer

Sep 11, 2015 7:30 PM

Tags: java tycho osgi

This post is partly to spread information publicly and partly a useful note to my future self for the next time I run into this trouble.

In OGSi, the primary type of entity you're dealing with is a "Bundle" or "Plug-in" (the two terms are effectively the same for our needs). However, there's a sort of specialized type that you may run into called a "Fragment". They're similar to a plug-in in that they're a contained unit of Java code and resources, but they have the special property that they're attached to another plug-in and automatically come along for the ride when the main plug-in is used. This is useful in a couple situations, such as code organization, serving platform-specialized native libraries, after-the-fact additions, or providing library dependencies.

In the basic case, the only requirement is to specify in the fragment what the "parent" plug-in is (Eclipse provides a field for this in its editor) and then including the fragment in the installable feature alongside the plug-in. However, there are a few situations where a bit more work is required if you want to access the classes in the fragment: when used as part of a Tycho build and when used as an XSP Library in Designer (which may also apply to Eclipse dependency use generally).

Tycho

When doing a full Tycho build, even if both the plug-in and its fragment(s) are part of the current build, another project won't automatically include the fragment when doing the compilation. This can lead to a situation where the projects will compile cleanly in Eclipse (which handles the fragment attachment) but fail in Tycho. The trick, though small, is non-obvious: you have to tell the project that is using the fragment code about the fragment in its build.properties.

So say you have three projects: the main plug-in (some.main.plugin), a fragment attached to it (some.main.plugin.fragment), and the project consuming them (some.dependent.plugin). The normal first step is to include the main plug-in in the dependent plug-in's MANIFEST.MF as usual:

Require-Bundle: some.main.plugin

In Eclipse, this will suffice: both the main plug-in and its fragment will show up in the "Plug-in Dependencies" library. For Tycho, though, you have to tip it off using a line like this in build.properties:

extra.. = platform:/fragment/some.main.plugin.fragment

Think of this as saying "hey, dummy, don't forget about the fragment". Once you have that line, the Tycho-enabled Maven build should be able to resolve the fragment's classes and all will be well.

Designer

When using the plug-in and its fragment in an XSP Library in Designer, there's a similar-seeming problem: though Designer will include any direct dependencies of your Library plug-in in the class path, it won't pick up on any fragments by default (though it seems that Domino does). The trick here is that the primary plug-in has to tell Designer that it accepts fragments, which is done by setting Eclipse-ExtensibleAPI in the MANIFEST.MF file for some.main.plugin, like so:

Eclipse-ExtensibleAPI: true

Once that's in place, the fragment should start showing up in your NSF's classpath when the library is enabled.
