XPages on Android

  • Apr 15, 2019

Around the start of the year, I had a bit of a dalliance with the idea of running XPages outside Domino. The upshot of that project is that it is indeed possible to do so, but there'd be some work to do to make it practical.

This month, we revisited the idea with a healthy dose of Darwino to provide some undergirding technology, with the goal of being able to run a plain old XPages app on mobile devices backed by Darwino DBs and replicating back to Domino. There was a lot of fiddling involved, but it works:

Android is the natural first target, but iOS is about 70% there, with the scaffolding loading up to the point where it loads a page but currently with a bit of trouble when it comes to resolving data classes and executing renderers.

What Specifically Is Going On?

We set out a few required parameters to call it a successful proof-of-concept:

  • It has to use the actual XPages framework - that is to say, the jar files shipped with Notes/Domino
  • The XPages themselves have to be shared among Domino and the Darwino app, in the form of their Java "intermediate" source (compiling from .xsp source is possible but is a whole other thing)
  • It has to use xp:dominoView and xp:dominoDocument data sources
  • It has to load the Extension Library
  • It has to use ancillary elements from the app: managed beans, themes, CSS, images, SSJS libraries

This checks all of those boxes, and it's pretty satisfying to see in action.

The Stumbling Blocks

As I discussed in my post about the original project, there are aspects of XPages that are meant to make this sort of thing possible, with the core parts abstracting out different platforms and runtime environments. Over the years, though, assumptions about Domino and OSGi crept in, with newer additions and the Extension Library taking a bit less care to be environment-neutral.

Moreover, XPages is not open source and I don't have any particular special access to it, making this whole thing essentially, in the video-game sense, hard mode. There are a handful of classes that needed to be outright swapped out, like the annoyingly-final NotesContext class, but there was much less of that than I'd thought.

After that, getting the data to point to Darwino was pleasantly straightforward. Other than a handful of areas where the NAPI comes in, the Domino data sources largely adhere to the rules of the lotus.domino interfaces and don't make assumptions about the implementing classes (this is essentially how ODA shims in as well).

What This Could Be Useful For

With the right fleshing out, this could be a real way to run existing XPages apps on mobile devices. That could be pretty useful on its own, but I don't think that carrying forward XPages apps as-is is the right idea. The side effect of this, though, is that you have a functioning XPages app in a normal old .war file project, structured with Maven or Gradle, and ready to be molded into newer frameworks using whatever tooling you'd like. No Designer, no OSGi, no Servlet 2.4/2.5, just a clean basis running your existing logic and ready to be improved.

If the mountain of existing XPages code is going to have a future, I think it should be something like this.

Implementing Cluster Replication From Domino to Darwino

  • Mar 19, 2019

Since its inception, Darwino has had two-way replication between it and Domino, and it's evolved over the years in fidelity and configurability. Recently, I was able to check an item off the to-do list that I've wanted for a while: "cluster-style" replication from Domino, where a document change immediately kicks off replication to Darwino.

Component #1: Extension Manager

Fortunately, the implementation is straightforward in concept: the Extension Manager has been in there since 4.0 and provides exactly the hooks one would need to implement this. The trouble with the Extension Manager, though, is that you can only subscribe to events from within an ExtMgr addin, and that means native code. You can't just hook into it from, say, an OSGi plugin.

My first thought was to use DOTS, which created this exact sort of bridge years ago. However, it's critically limited: the EM ferrying was never really fleshed out that much, and nor will it ever be, since it's not a supported project. It was kind-of-sort-of supported in the 9.x era for "social" purposes, but those days are behind us. Moreover, its separate OSGi environment wouldn't suit Darwino's needs particularly well.

The DOTS dynamic library, though, could still be potentially useful. Nathan Freeman came across this a couple of years ago: due to the way the DOTS dylib ferries the events from the ExtMgr world to DOTS, the channel is actually consumable by anything, not just DOTS specifically. My initial implementation did exactly this: it fed from the fountain of messages produced by the DOTS dylib for its own ends.

However, the core trouble still remains that DOTS isn't supported as such, and it has too many moving parts for us to want to take on as a dependency. Moreover, the "siphoning" only works if there's only one subscriber listening - on a server that also runs ODA (which Darwino does not use), you have the two consumers contending for messages, which is a recipe for missed events.

So I decided to write a custom-made ExtMgr addin, which would have the advantages of being much smaller and easier to maintain, feeding a different queue, and being a fun learning opportunity for me. The last part isn't as important to Darwino-the-product per se, but I always like when it lines up like that.

Component #2: Message Queues

The way DOTS and this new addin do their things is to use Message Queues, another technology presumably-not-coincidentally added to Domino in R4. The way these work is that you create a named queue (DOTS's, for example, is named MQ$DOTS) and then feed it strings, which are then consumed by anything running in the same Notes/Domino environment by requesting the queue of the same name and waiting for messages. It's pretty simple both in theory and in execution, with the minor problem that the API isn't officially available from Java.

Fortunately for ODA's (and presumably DOTS's) use, though it's not part of the official API, there is a lotus.notes.internal.MessageQueue class that is a (shockingly-thin) wrapper around the MQ* functions in the C API. It's functional, and the thinness of the wrapper means that the method parameters, though unnamed in the bytecode as usual, are clear matches for the equivalent C parameters.

I initially started using this, but ended up writing a nicer wrapper in Darwino's NAPI that implements BlockingQueue, making consumption in Java much clearer.

Component #3: The Listener

The final piece was the most comfortable, since it's entirely back in the warm embrace of Java: I wrote a class to listen for events coming through this queue, extract the database name, check for replicators configured for that NSF, and immediately kick any applicable ones off.

The End Result

Since the overhead of the work in a small replication is so minor, the end result is effectively the same as cluster replication between Domino servers: the change/creation/deletion is propagated over within a couple milliseconds (for small documents, due to, you know, physics). It's pretty satisfying to see in action.

Pub/Sub

If you've been following HCL's announcements lately and feel like this sounds very similar to the pub/sub support they've slated for V11, you're right. My guess is that they wanted to get Elastic Search working with low latency and (kindly and wisely) decided to turn the work required into a nicer interface for the same EM events we're using. It's a good feature and, assuming it's consumable from local Java, would have made my work here easier, but I didn't want to wait, and we target a couple Domino releases back anyway.

Anatomy of a Clean Open-Source Project

  • Mar 18, 2019

Over the years, initially thanks to Peter Tanner's diligent work as the OpenNTF IP Manager and now my own occupation of that seat, I've learned to really appreciate the virtues of dotting your "i"s and crossing your "t"s when it comes to making an open-source project legally clean and clear.

It's definitely something I underrated early on, though - caring about the specific differences between licenses and, in particular, maintaining things like per-file license/copyright headers felt like annoying busywork. For a project that only you will ever use, it technically is, but the hope of open source is that you'll get other people using your work and, ideally, contributing back in turn, and that's when it's important to make sure you have everything sorted out.

Why Bother?

Well, for one, you or your users could theoretically be sued or otherwise legally entangled if you don't keep track of this stuff. Admittedly, it's fairly unlikely, but the consequence of, for example, unknowingly including GPL software in your proprietary product is potentially significant.

It's for that sort of reason that it's important to make sure everything is clean before some large corporations will risk even looking at your project. IBM is particularly good about this because they were significantly burned in the past, and came out of it with extremely-strict view, and that rubbed off on OpenNTF both culturally and with their gracious technical assistance along the way.

And, since large consumers require this sort of vetting, it's also important to know how to do it if you want to contribute code to an open-source organization like OpenNTF, Eclipse, or Apache.

It's also surprisingly satisfying once you get into the swing of it, I've found.

The Example Project

Since I've been spending a lot of time recently with the NSF ODP Tooling project, we'll look at its GitHub repository.

Common Files

There are a couple common features that tend to show up, and which both people and tooling (like GitHub's license identifier) look for:

  • The LICENSE file, which is the most critical. This contains the text of the license you're using, as well as one of the declarations of the copyright year (though, admittedly, it's easy to forget to include that part). This is what declares the effective license for the code in the repository that you own the copyright to, and should be included right from the start if possible.

  • The NOTICE file, which is vital if you're including any code from any sources not covered under the main copyright. This file should list all of the third-party code you have included in the repository, its license type, and, if possible, where to acquire it. If your project's distributable form includes additional third-party code not included in the repository (such as Maven or npm dependencies), these should be enumerated here as well

    • Writing this file has an important side effect in that it forces you to account for the licenses of your dependencies. More than once, I've run into a situation where I found that a common dependency had an incompatible license (such as the pure GPL). In some cases, this has meant abandoning the dependency outright, while in others it has meant finding a better-licensed alternative. Eclipse Orbit exists in large part for this purpose.
  • A legal directory containing any additional license/redistribution information not covered by the NOTICE. This can also sometimes take the form of files like NOTICE-Weld in the root of a project, and is useful for mass-including copyright/notice information from third parties in their original form.

In addition to including these files in the project repository, you should also make sure to include them in any binary distributions you make. In my projects, this takes the shape of inclusions in a Maven Assembly Plugin packaging file.

File Headers

I originally chafed against the idea of per-file copyright/license headers. They're not strictly necessary when the files are included in the original repository, they're redundant, you end up with massive commits touching hundreds of files just to change a year, and they can dwarf the size of the actual code they're copyrighting.

However, I've really come around to the practice of including them, and the main reason is that it makes the files easier for others to copy and use legally. It's one thing when someone finds their way to the root of your repository or distribution package, but it's another when they find an individual class by doing a web search or hitting F3 in Eclipse. In those cases, they can find their way up to the license (assuming your source package includes it), but it's much easier if it's just declared right up front.

It's also easier to clearly distinguish the third-party code you're including. When each file has its copyright information clearly noted, you can easily tell the difference between a sui-generis project file and an included third-party file without having to parse through the NOTICE every time.

And, fortunately, it doesn't have to be a huge hassle to maintain. In each of my Maven projects, I include a license plugin configuration to declare copyright information, any special data types, and which files to not include. Then, whenever I add new files or make a change after the turn of a year, I can run mvn license:format and it'll keep everything tidy for me.

pom.xml Configuration

Maven (and it's not alone in this) provides a lot of pom.xml-level elements to declare all sorts of metadata about your project, like its SCM repository, issue tracker, and, critically, license and developers. I like to declare the inception year, the license, and the <developers> block:

	<inceptionYear>2018</inceptionYear>

	<licenses>
		<license>
			<name>The Apache Software License, Version 2.0</name>
			<url>http://www.apache.org/licenses/LICENSE-2.0.txt</url>
		</license>
	</licenses>

	<developers>
		<developer>
			<name>Jesse Gallagher</name>
			<email>jesse@frostillic.us</email>
		</developer>
	</developers>

I use that <inceptionYear/> value as part of the license-header file to keep track of the copyright range, at least when there's contiguous multi-year development.

OSGi Stuff

Since most of my projects are still OSGi, I've been aiming to improve my licensing setup there too. The main place where this comes into play is in feature.xml files, which have required elements to specify the copyright and license. It's not terribly unusual for these to end up as their "[Enter Copyright Description here.]" defaults, but it's important to fill these in. They're included in the "accept the licenses" dialog when installing into Eclipse/Designer, and are available in the "Installed software" descriptions in the UI.

But What License to Use to Begin With?

I'll finish off this post with what is actually the most important part of the process, but which can usually be answered simply. There are a lot of open-source licenses out there, and you could theoretically make up your own, but for our purposes the choice tends to follow some basic rules:

  • If you're contributing to an established OS organization, use theirs - for example, if you're contributing to Eclipse, use the EPL.

  • If you want your code to be mixed other OS projects and (potentially) proprietary ones, pick Apache or something like it.

    • At OpenNTF, we have a preference for Apache over other similar licenses, because it's well-established and makes copyright handling clearer than the equivalents, something that is critical for large companies. Let past lawyers do your legwork on this one.
  • If you want to require that users of your code keep the code open source, consider the GPL.

    • Be extremely wary of this, however: the GPL is intentionally "infectious" and limits how the code can be used. Various projects carve out little exceptions to the GPL to allow use in otherwise-non-GPL products, but it's still something of a minefield.
    • The GPL is one of the approved licenses for OpenNTF, but we kind of discourage it except in cases where a project is GPL because it's derived from previously-GPL'd code.
  • If you don't want to be bothered too much by copyright and just want the code out there, consider Public Domain. In practice, it's usually best for you to retain copyright, but explicitly declaring Public Domain is certainly an effective way of allowing any use.

For projects in our community, the quick answer is "use Apache". It's permissive, covers copyright, and is known and trusted by pretty much everyone.

More Work Than It's Worth?

Both the earlier parts of this post and Betteridge's Law contribute to making it clear that my answer is "no, it's not more work than it's worth", but I can certainly see why it'd feel that way. The first couple times I submitted projects to OpenNTF and got a "here's some stuff to fix" email from Peter Tanner, part of me definitely chafed at the whole thing. That can be particularly the case for Notes-based contributions - sometimes, you just want to plunk an NTF on the project page and be done with it, and Notes certainly doesn't have a "wrap this NSF copy in a ZIP with LICENSE and NOTICE files" checkbox.

However, as I learned more about the legal importance of having licenses correct and got more practice at doing this stuff from the start, I started to appreciate the whole process. It also turned out to be really helpful to sort this stuff out on smaller projects before working on larger ones, especially ones with established teams and procedures.

In all, it's worth it both to allow you to contribute to larger projects and, regardless of project size, it's worth it for anyone consuming your code.

Java With Domino After XPages

  • Mar 14, 2019

IBM and HCL held a webcast today to detail some plans for Notes/Domino V11. There were some interesting tidbits elaborating on things like the pub/sub support, and it'll be worth tracking down a recording of the event when it's available.

What's important for this series, though, is that this event served as the long-promised "roadmap" announcement for XPages. The roadmap is, in effect, option three: HCL plans to look into ways to reuse some existing XPages code, but in general you should be aiming to write your UIs in something else, either consuming REST services from an XPages container or accessing Domino data via another route (like the domino-db Node.js module and hypothetical Java gRPC client).

So we know the end of the path: not XPages. However, it's not like we're all just going to throw away our existing apps, so there's work to do determining how we're going to get there. The options remain pretty much what they were after CollabSphere last year, albeit now with the doubt removed. The first two options - returning to LotusScript or going to Node - have their advantages and disadvantages, and you could make a reasonable case for either. Personally, I'm not interested in going down those roads, though, and I think it's better for any app of reasonable complexity to dive into Java. Other members of the community and I have developed tools over the years to make it easier, and now's the time to take some of these steps if you haven't already.

Do Not Use Server JavaScript

Sever JavaScript was always something of a trap for app architecture. There's nothing inherently wrong with having a scripting language on your UI pages, and it certainly helped bridge some gaps, but the way it and Designer intertwined encouraged developers to create non-portable messes. If you're still writing SSJS, stop immediately.

Learn Proper Java

Java has been around for a long time, and the way to right "good" Java code has changed over time and varies greatly by your environment. Some aspects, though, apply generally, and it's useful to stay up-to-date on current practices. I don't know a better resource for this than Effective Java, which has been updated for Java 7-9 since I last read it.

Speaking of which, you should learn about Java 8 streams and lambdas - they're great. Julian Robichaux did a presentation on this topic back at Connect 2017, and the slide deck is very elucidating.

Adopt Standard Java Technologies

Last year, I created a project to bring some modern JEE technologies to XPages. These are some of the same technologies I've been talking about in my "XPages to Java EE" series and, while that project can't bring the full JEE development experience to XPages, using those tools will help you write code that, in some cases, could be directly dropped into a Java EE app with no modifications at all. There's a big asterisk when it comes to actually accessing Domino data, but that's a solvable problem as well (with some more development).

In particular, you should start writing JAX-RS services. Not only is JAX-RS an excellent and very-capable spec, but REST services are portable to absolutely any front end.

Adopt Automated Builds

Maven has been something of a bugaboo for XPages developers for a while, but doesn't have to be. Node development (server- or client-side) revolves around npm and various build plugins, and Maven is much the same thing. One of the biggest improvements I've made lately to all of my active XPages apps is to wrap the on-disk project for them inside a Maven artifact, using the NSF ODP Tooling. That project allows you to automatically build your NSFs alongside other parts of the project (such as OSGi plugins) without having Designer involved.

Check the example project in that repo, and stay tuned for a 2.0 release (probably) imminently.

Learn Other Toolkits

If you're just starting the process of figuring out what to do after XPages, it doesn't particularly matter which other toolkit you learn, as long as it's reasonably modern. If you take some time to learn how to make, say, a React app but end up going with something else down the line, the lessons you learn will apply very closely. A particularly-comfortable option could be to learn JSF, which has a common ancestry with XPages but has up-to-date capabilities.

Whatever it is, though, just learn some other toolkit.

Follow Channels and Accounts for Other Tech

Over the last couple months, I've started following a lot of Jakarta-related blogs and Twitter luminaries. This applies elsewhere - even if you're not using other toolkits yet, it's very helpful to start immersing yourself in the news and culture.

Don't Stay Still

The primary thing to take to heart is the importance of doing something. Unless you're planning to change careers or retire in the short term, you'll have to make one decision or another. XPages is not going to get meaningfully better, and even existing apps will get worse with time as browsers and technology change.

Other environments, though, are already leagues ahead and are constantly improving. Dive in; the water's fine!

XPages to Java EE, Part 13: Why Do This, Anyway?

  • Mar 1, 2019

In the introductory post to this series, I started by saying that I've come around to the idea that Java EE (and its kindred technologies) is the future for Java development with Domino, and I think it's worth taking some time to make the case that you should think so too.

A lot of it starts with a nagging question:

Is XPages Dead?

Speaking very strictly, no. XPages remains a component of a commercial product and so bug reports receive attention and fixes as they occur, and presumably all of the many problems the platform is bound to run into as the world evolves will also be addressed.

However, I think the more important question is:

Does It Even Matter If XPages Is Technically Not Dead?

At this point, XPages has, for almost its entire existence inside Domino, been "living" the peculiar kind of undeath that afflicts enterprise software. This is the sort of undeath you could see in, for example, IRIX, which had its last major release in 1998 but was "supported" with maintenance releases for another eight years. XPages has similarly had a few new features since the initial ExtLib release in the 8.5.2 era era - such as the Bootstrap renderkit and some quality-of-life bits - but it's clearly been in maintenance mode for a while. It's been a reactive type of maintenance, too: since XPages doesn't have the Notes-client-app advantage of existing in a controlled environment, XPages development has been increasingly a story of something breaking in some browser and harassing IBM or HCL until there's a fix.

"But wait," you might say, "HCL is going to be in charge now, and look how they're revitalizing the core of Domino! Maybe they'll do the same for XPages!" And, well, maybe they will. I doubt it, though - the core team they brought over isn't involved with XPages, and in general IBM and HCL seem to think so little of it that they don't capitalize it correctly in slides. HCL's development strategy seems to (defensibly) focus on porting the Notes client to other platforms and encouraging developers to either crawl back to LotusScript or to use development stacks that HCL isn't on the hook for, like Node.

And, even if they did staff up to enhance XPages, would it be wise to depend on that? It would still be a single-vendor stack using technologies (OSGi) and idioms (server-side page state) that work but aren't the way the wind is blowing. I would expect that any renewed push would be short-lived.

Okay, Grumpy Gus, Why Is Java EE Any Better?

There was a period in the recent past where Java EE was hitting some similar trouble: Oracle largely lost interest in Java EE (and Java in general, to a lesser extent) and development slowed. However, because so much was open source and (critically) the development pool was so much larger, things kept moving along, with the insurgent group of MicroProfile building new technologies. The transfer of Java EE to Eclipse has proven to be a blessing as well, with the community taking up the mantle splendidly.

As with anything, there's no absolute guarantee of a future path, but JEE has the critical mass that XPages doesn't, with community members and companies emotionally and financially invested in its future. There's no one company whose loss of interest would doom the whole thing, even the Java rump state at Oracle.

And, in the mean time, the technology is just better. You can use current versions of Java, new web technologies are adopted immediately, the IDEs are significantly more stable and featureful, the whole stack has source and Javadoc readily available, the surrounding tooling is better, the modern APIs are simpler and more descriptive, and so forth. Even though XPage's cousin, JSF, has lost some interest, it has evolved significantly past the point where XPages forked away - and is also just one of many good options for app development.

This Is The Bridge We Were Promised

When XPages was ported into Domino, one of the ancillary features for developers was that it would provide a path to the "real" development world, out of our abusive cell of Domino's legacy web stack. It meant being able to consume common Java libraries more practically than in Java agents, extending the capabilities of the platform ourselves, and using development practices that are closer to the rest of the world.

And, to a large extent, these promises came true. We've had the ability to work with the Servlet spec directly, we've been bringing in libraries like Poi with only medium-sized hurdles, and we've been able to (kind of) break the mental binding between the UI and data storage.

Now it's time to truly cross the bridge. There's still a case to be made for writing new XPages applications for now, but every line of XSP markup should be acknowledged as new technical debt. At this point, you should either start working towards Java EE or have a clear plan for how you're going to get there. It doesn't have to be Java EE: there's a lot to be said for taking up HCL on their suggestion to write Node apps, and there are other Java and non-Java frameworks out there that are actively advancing. Regardless of your choice, if you don't choose something, your development will remain stunted and you'll be at a near-guaranteed risk of some critical security problem showing up in an old Dojo version or some other part of the stack and having to clamor for an emergency fix that would otherwise be a one-line pom.xml or package.json tweak (if needed at all).

It's also just very pleasant - give it a try.

XPages to Java EE, Part 12: Container Authentication

  • Feb 20, 2019

Coming from Domino, we're both spoiled by the way it handles users and authentication. The server comes with an implicit directory far removed from the app, and so we just use that. Moreover, the HTTP "container" handles authentication for us: we configure whether we want HTTP Basic auth, simple session auth, LTPA, or SAML (I guess) authentication at the server/web site level, also far from the app. Then, in the application, we just set up an ACL in the DB or XPage and reader/author fields on notes and let the server take care of it.

We're also pretty constrained by this, as anyone who has wanted to set up a custom in-app login page, in-app user registry, or even server-level specialized user repository knows. The convenience comes with a cost.

Java EE's Routes

Authentication in Java EE has a complicated history, but the general idea is that there are three main current ways to handle user registries and authentication:

  1. Container authentication, which is roughly equivalent to Domino. In this case, you configure your server with knowledge about the user registry (say, a static set of users or an LDAP server) and how those users map to "roles" in the JEE sense (more on this in a bit), and then your app just tells the server what parts need login.
  2. Per-app custom authentication. This is roughly equivalent to doing a special in-app session cookie in a Domino app for authentication, but the hooks provided by Java EE make it easier to manage. You could do this entirely homebrew or use a project like Apache Shiro to do the heavy lifting for you.
  3. The Java EE Security API 1.0. This is a new standard, introduced in Java EE 8, meant to give apps the fine-grained custom control of the second option while offloading as many particulars as desired to the servlet container - essentially, a "best of both worlds" approach. In practice, I've found it a bit under-documented and fiddly in its current incarnation, but I'll aim to cover it in a future post.

Container Authentication

For this post, I'll cover setting up container authentication, since it's the easiest, is well-documented, and can even serve the "per-app" role if you follow the "one app per server" model that's in vogue for microservice/"cloud native" applications.

For testing and development cases, web servers generally provide a mechanism for writing out a simple user/password list. Open Liberty does this via server.xml and Tomcat/TomEE does it via tomcat-users.xml. However, since we're Domino people, that means we have access to an LDAP server we're already comfortable with running, so we can jump right into a "real" setup.

Configuring Domino for LDAP

This topic is a bit out of the bailiwick of this series, but usually it just means creating an LDAP Internet Site and running load ldap. Domino's pretty convenient sometimes. I like to test a freshly-configured LDAP server with Apache Directory Studio.

Configuring Liberty

Once you have LDAP running and working, open Liberty's "server.xml" file (dubbed "Server Configuration" in Eclipse's Servers view) and add the ldapRegistry-3.0 feature and an ldapRegistry element within the top-level server element, customized for your setup:

<featureManager>
    <feature>javaee-8.0</feature>
    <feature>localConnector-1.0</feature>
    <feature>mpOpenAPI-1.0</feature>
    <feature>ldapRegistry-3.0</feature>
</featureManager>

<ldapRegistry host="some.domino.server" port="389" sslEnabled="false"
    	bindDN="someuser" bindPassword="somepassword"
    	ldapType="IBM Lotus Domino" baseDN=""/>

There are ways to prevent putting an unencrypted password in the "server.xml" file, but this will do for now.

As a nice bonus, Liberty's IBM provenance means we get built-in knowledge of Domino and so don't have to jump through the common hoops of setting up query filters and whatnot.

The other bit of configuration in this file is to map users and groups to roles. This is an area where Domino and JEE diverge a bit. "Roles" in JEE mean more or less the same thing as in Domino, but they're configured outside of the application. They can be configured per-app within the server configuration, accomplishing the same end result, but there's a different level of indirection. For our users, we'll configure them server-wide. So, add another element as a peer to the ldapRegistry:

<authorization-roles>
  <security-role name="admin">
    <group name="LocalDomainAdmins"/>
  </security-role>
</authorization-roles>

You can feel free to customize this at will - there's also a user type and the concept lines up pretty much with what you'd expect.

Configuring the App

The server configuration on its own doesn't yet change anything - we can still visit any page in the app without a login prompt. What we should do now is to clamp down certain aspects. To demonstrate this, we'll add a UI operation for deleting people and restrict it to our freshly-minted "admin" role. Go to the PersonController class and add the method:

@POST
@Path("{id}/delete")
@RolesAllowed("admin")
@Controller
@Operation(hidden=true)
public String deletePerson(@PathParam("id") String id) {
  personRepository.deleteById(id);
  return "redirect:people"; //$NON-NLS-1$
}

Note that we're using POST for this instead of DELETE as a nod to web browsers' historical limitations. There is a way to intercept and remap incoming requests so that we can use @DELETE annotations that I may cover later, but for now this should work fine.

Modify the "personList.tag" file within "WEB-INF/tags" in "Deployed Resources" to include a button to point to this action:

<%@tag description="Displays List&kt;model.Person&gt;" pageEncoding="UTF-8" trimDirectiveWhitespaces="true" %>
<%@attribute name="value" required="true" type="java.util.List" %>
<%@taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>

<h1>People</h1>
<table>
	<thead>
		<tr>
			<th>ID</th>
			<th>Name</th>
			<th>Email Address</th>
			<th></th>
		</tr>
	</thead>
	<tbody>
		<c:forEach items="${pageScope.value}" var="person">
		    <tr>
		    	<td><c:out value="${person.id}"/></td>
		    	<td><c:out value="${person.name}"/></td>
		    	<td><c:out value="${person.emailAddress}"/></td>
		    	<td>
		    		<form action="${pageContext.request.contextPath}/resources/people/${person.id}/delete" method="POST">
		    			<input type="submit" value="X"/>
		    		</form>
		    	</td>
		    </tr>
		</c:forEach>
	</tbody>
</table>

If you visit http://localhost:9091/javaeetutorial/resources/people and click one of the deletion buttons, you should be greeted with an HTTP Basic authentication prompt that should block you until you enter in valid credentials for an admin.

Next Steps

At this point, we've really covered the main aspects that you'd need to know when making the move to Java EE. After this point, I have some ideas for various miscellaneous posts - other authentication options, app fit and finish, JSF, app configuration, deployment, and so forth - but, if you've been following along, I suggest you take the opportunity now to explore for yourself.

It would also be worth your time to look up some other existing educational resources. I hear that Java Brains is quite good on a lot of these topics, and Adam Bien is one of the leading sources for Java EE examples (and is the source of the template we used at the very start). When looking around, be wary of the age of the content: though pretty much anything related to Java EE will still work, there was a big move away from the Bad Old Days in recent versions, particularly EE 8, and so older examples may have you jump through uglier hoops than necessary. There are also whole technologies that are in common use that are not of immediate interest to us, such as Enterprise JavaBeans, so you can learn or not learn about those at will.

XPages to Java EE, Part 11: Mixing MVC and an API

  • Feb 16, 2019

When we set up our MVC controller classes, we put the @Controller annotation at the class level, which tells the environment that the entire class is dedicated to running the UI. However, we don't necessarily always want to do that - JAX-RS is the way to build REST APIs, after all, and so we should also add JSON versions of our Person methods.

Person Model Modification

Before we get to the meat of the code, go back to the Person class and modify it to remove the parameter to the @Id annotation and switch it to a String type:

package model;

import javax.validation.constraints.Email;
import javax.validation.constraints.NotBlank;
import javax.ws.rs.FormParam;

import org.jnosql.artemis.Column;
import org.jnosql.artemis.Entity;
import org.jnosql.artemis.Id;

@Entity
public class Person {
	@Id
	private String id;
	@Column @FormParam("name") @NotBlank
	private String name;
	@Column @FormParam("emailAddress") @NotBlank @Email
	private String emailAddress;

	public String getId() { return id; }
	public void setId(String id) { this.id = id; }
	public String getName() { return name; }
	public void setName(String name) { this.name = name; }
	public String getEmailAddress() { return emailAddress; }
	public void setEmailAddress(String emailAddress) { this.emailAddress = emailAddress; }
}

The reason for the change is that my original example was based on code from an older version of JNoSQL, and long IDs end up causing trouble when updating existing documents.

Also go to PersonRepository and modify it to use a String for the key:

package model;

import java.util.List;

import org.jnosql.artemis.Repository;

public interface PersonRepository extends Repository<Person, String> {
	List<Person> findAll();
}



Tweaking the Controller

The first step to adding in API methods doing this is to move the @Controller annotation down to just the methods that emit JSP responses (and adjust for the changed ID field while we're here):

package com.example;

import java.util.Random;

import javax.enterprise.context.RequestScoped;
import javax.inject.Inject;
import javax.mvc.Controller;
import javax.mvc.Models;
import javax.validation.Valid;
import javax.ws.rs.BeanParam;
import javax.ws.rs.GET;
import javax.ws.rs.POST;
import javax.ws.rs.Path;

import org.bson.types.ObjectId;
import org.jnosql.artemis.Database;
import org.jnosql.artemis.DatabaseType;

import model.Person;
import model.PersonRepository;

@Path("/people")
@RequestScoped
public class PersonController {
	@Inject
	Models models;

	@Inject
	@Database(DatabaseType.DOCUMENT)
	PersonRepository personRepository;

	@GET
	@Controller
	public String home() {
		models.put("people", personRepository.findAll()); //$NON-NLS-1$
		return "person-new.jsp"; //$NON-NLS-1$
	}

	@POST
	@Controller
	public String createPerson(@BeanParam @Valid Person person) {
		if(person.getId() == null || person.getId().isEmpty()) {
			person.setId(new ObjectId().toHexString());
		}

		models.put("person", personRepository.save(person)); //$NON-NLS-1$
		models.put("people", personRepository.findAll()); //$NON-NLS-1$
		return "person-created.jsp"; //$NON-NLS-1$
	}
}

Doing this shouldn't change the behavior of the app, and that's what we want.

Add Some API methods

Now, to be a proper REST API, we'll want a suite of Create-Read-Update-Delete methods using standard HTTP verbs. Add these methods to the class:

@GET
@Produces(MediaType.APPLICATION_JSON)
public List<Person> list() {
  return personRepository.findAll();
}

@GET
@Path("{id}")
@Produces(MediaType.APPLICATION_JSON)
public Person getPerson(@PathParam("id") String id) {
  return personRepository.findById(id).orElseThrow(() -> new javax.ws.rs.NotFoundException("Could not find person for ID " + id)); //$NON-NLS-1$
}

@POST
@Consumes(MediaType.APPLICATION_JSON)
@Produces(MediaType.APPLICATION_JSON)
public Person createPersonApi(@Valid Person person) {
  if(person.getId() == null) {
    person.setId(new ObjectId().toHexString());
  }
  return personRepository.save(person);
}

@DELETE
@Path("{id}")
@Produces(MediaType.APPLICATION_JSON)
public JsonObject deletePersonApi(@PathParam("id") String id) {
  personRepository.findById(id).orElseThrow(() -> new javax.ws.rs.NotFoundException("Could not find person for ID " + id)); //$NON-NLS-1$
  personRepository.deleteById(id);
  return Json.createObjectBuilder()
      .add("success", true) //$NON-NLS-1$
      .build();
}

@PUT
@Path("{id}")
@Consumes(MediaType.APPLICATION_JSON)
@Produces(MediaType.APPLICATION_JSON)
public Person updatePersonApi(@PathParam("id") String id, @Valid Person person) {
  person.setId(id);
  return personRepository.save(person);
}

Here, we're taking advantage of JAX-RS's MIME-type-based routing: because our @Controller methods deal with HTML but these new methods declare that they're working with JSON, JAX-RS will route incoming browser visits to the controller and incoming API requests to the others.

Testing It Out

We can see this in action by trying out the API from the command line (or with a REST client app like Postman):

$ curl -i http://localhost:9091/javaeetutorial/resources/people
HTTP/1.1 200 OK
X-Powered-By: Servlet/4.0
Content-Type: application/json
Date: Sat, 16 Feb 2019 17:05:16 GMT
Content-Language: en-US
Content-Length: 246

[{"emailAddress":"api@test.com","id":"5c683fd40048ce11b5f6aee8","name":"API Test"},{"emailAddress":"foo@foo.com","id":"5c6841520048cea7c9f6c2d5","name":"Foo Fooson"},{"emailAddress":"foo@foo.com","id":"5c6841690048cea7c9f6c2d7","name":"API mod"}]

$ curl -i -X POST -H"Content-Type: application/json" http://localhost:9091/javaeetutorial/resources/people -d "{\"emailAddress\":\"foo@foo.com\",\"name\":\"Created with cURL\"}"
HTTP/1.1 200 OK
X-Powered-By: Servlet/4.0
Content-Type: application/json
Date: Sat, 16 Feb 2019 17:11:55 GMT
Content-Language: en-US
Content-Length: 89

{"emailAddress":"foo@foo.com","id":"5c68445b0048cea7c9402b85","name":"Created with cURL"}

$ curl -i -X PUT -H"Content-Type: application/json" http://localhost:9091/javaeetutorial/resources/people/5c68445b0048cea7c9402b85 -d "{\"emailAddress\":\"foo_mod@foo.com\",\"name\":\"Modified with cURL\"}"
HTTP/1.1 200 OK
X-Powered-By: Servlet/4.0
Content-Type: application/json
Date: Sat, 16 Feb 2019 17:12:30 GMT
Content-Language: en-US
Content-Length: 94

{"emailAddress":"foo_mod@foo.com","id":"5c68445b0048cea7c9402b85","name":"Modified with cURL"}

$ curl -i -X DELETE http://localhost:9091/javaeetutorial/resources/people/5c68445b0048cea7c9402b85
HTTP/1.1 200 OK
X-Powered-By: Servlet/4.0
Content-Type: application/json
Date: Sat, 16 Feb 2019 17:12:54 GMT
Content-Language: en-US
Content-Length: 16

{"success":true}

OpenAPI Documentation

OpenAPI is the boring-ified name of the standardized spec of Swagger, a mechanism for documenting REST APIs - kind of like what WSDL is for SOAP web services. This spec has become an important part of MicroProfile, the set of Java server technologies geared towards writing microservices that shares a lot of core technologies with Java EE. One of the niceties that MicroProfile includes is an automatic OpenAPI generator for JAX-RS services. There are a few things to add to our environment to enable this, but not too much.

To begin with, we'll have to enable the OpenAPI generator feature in Open Liberty (TomEE may have something like this; I don't know). To do that, open up the "server.xml" file (labeled "Server Configuration" in Eclipse's Servers view) and add "mpOpenAPI-1.0" to the feature list:

<featureManager>
    <feature>javaee-8.0</feature>
    <feature>localConnector-1.0</feature>
    <feature>mpOpenAPI-1.0</feature>
</featureManager>

Doing that alone will enable the API documentation, available at http://localhost:9091/openapi. However, if you look closely at the output, you'll see it's not exactly what we'd want: the GET operation for /resources/people points to our MVC home method, which it considers an unstructured string. It also lists the "helloworld" and "markdown" resources, and you can feel free to delete those classes outright - we won't be returning to them.

To fix this, first go to the project's "pom.xml" and add a dependency on the MicroProfile OpenAPI spec:

<dependency>
    <groupId>org.eclipse.microprofile.openapi</groupId>
    <artifactId>microprofile-openapi-api</artifactId>
    <version>1.1</version>
    <scope>provided</scope>
</dependency>

This is another one we can mark as "provided" since the implementation is included with the server.

Now, go back to the PersonController class, add an import line for org.eclipse.microprofile.openapi.annotations.Operation, and annotate the two MVC methods to mark them hidden from OpenAPI:

@GET
@Controller
@Operation(hidden=true)
public String home() {
  models.put("people", personRepository.findAll()); //$NON-NLS-1$
  return "person-new.jsp"; //$NON-NLS-1$
}

@POST
@Controller
@Operation(hidden=true)
public String createPerson(@BeanParam @Valid Person person) {
  if(person.getId() == null) {
    person.setId(new ObjectId().toHexString());
  }
  personRepository.save(person);

  models.put("person", person); //$NON-NLS-1$
  models.put("people", personRepository.findAll()); //$NON-NLS-1$
  return "person-created.jsp"; //$NON-NLS-1$
}

Now, if you refresh the /openapi output, you can see that it switched to the list method, and it knows that it outputs JSON, and includes a reference to the Person object structure at the bottom of the file.

There's a good deal more you can do with these annotations to customize the output, but it's nice to know that you can get an immediately-useful file that could be used to generate structured client libraries "for free".

Next Steps

Next, I think we'll dive into the world of Java EE authentication, which will be a very-different experience from what we're used to with Domino, for better and for worse.

XPages to Java EE, Part 10: Data Storage

  • Feb 15, 2019

How you store your data in an application is a potentially-huge topic, which is one of the reasons I've pushed it off for a while.

Designer's Curse

This is particularly the case because of the habits we learned over the years as Domino developers. One of the most grievous wounds Domino inflicted on us was an encouragement to always write directly to the data-storage implementation objects - forms and views for Notes client design or the lsxbe/lotus.domino classes for LotusScript and Java. They work, sure - fetching a document, setting fields, and storing it will get the job done - but it's an extremely-bad habit to work without a model framework and some level of indirection. Various people, including me, have made valiant efforts to add a model/DAO layer into XPages development in particular, but they've met with little uptake outside the individual developers who wrote them.

Fortunately, Java EE does not suffer from this specific brain poison, and it has a long history of abstracted data access, primarily via the Java Persistence API, traditionally backed by a JDBC driver for a SQL database. The point of an API like that is to let you write your model objects with just some annotations to explain to JPA bits about how it should be stored, and JPA will take care of the dirty work of actually mapping data types, writing queries, fetching data, and so forth.

JNoSQL

We won't be using JPA for this example, though. Instead, we'll be adding our second incubating spec: JNoSQL. JNoSQL is intended to be essentially "JPA for NoSQL", a largely-rethought API that won't crash into the hackiness of Hibernate's valiant attempt of re-using JPA directly. JNoSQL is currently slated for standardization as part of Jakarta EE and is under active development, but reached a point a while ago where it's good for use.

However, while there's technically a Domino JNoSQL driver that I put together last year, it's more of a POC than a real thing, and we'll skip it for this. For my uses, I've been using Darwino, which does have a splendid JNoSQL driver, but this series isn't the place to go through getting set up with that. For simplicity's sake, we'll be using MongoDB, which is quick to set up and is probably the furthest-developed driver in core JNoSQL.

MongoDB

So, to start out with, install MongoDB somewhere locally. This differs system-by-system - on Linux and macOS, I think it's available with package managers, or for any OS you can download an installer from their site.

Once it's installed, create a database named "exampledb" and a collection within it named "Person", as seen here with Compass, the standard admin app.

MongoDB collection configuration

Add the Driver

In your project's "pom.xml", add the JNoSQL document DB packages and MongoDB driver to your dependencies block:

		<!-- JNoSQL -->
		<dependency>
			<groupId>org.jnosql.artemis</groupId>
			<artifactId>artemis-core</artifactId>
			<version>0.0.7</version>
		</dependency>
		<dependency>
			<groupId>org.jnosql.artemis</groupId>
			<artifactId>artemis-document</artifactId>
			<version>0.0.7</version>
		</dependency>
		<dependency>
			<groupId>org.jnosql.artemis</groupId>
			<artifactId>artemis-validation</artifactId>
			<version>0.0.7</version>
		</dependency>
		<dependency>
			<groupId>org.jnosql.diana</groupId>
			<artifactId>mongodb-driver</artifactId>
			<version>0.0.7</version>
		</dependency>

For reference, "artemis" in JNoSQL terms refers to the mapping API - the annotations we're going to use - while "diana" refers to the driver portion.

Create the Configuration Class

Create a new class in the model package called DocumentCollectionManagerProducer:

package model;

import java.util.Collections;
import java.util.Map;

import javax.annotation.PostConstruct;
import javax.enterprise.context.ApplicationScoped;
import javax.enterprise.inject.Produces;

import org.jnosql.diana.api.Settings;
import org.jnosql.diana.api.document.DocumentCollectionManager;
import org.jnosql.diana.api.document.DocumentCollectionManagerFactory;
import org.jnosql.diana.api.document.DocumentConfiguration;
import org.jnosql.diana.mongodb.document.MongoDBDocumentCollectionManager;
import org.jnosql.diana.mongodb.document.MongoDBDocumentCollectionManagerFactory;
import org.jnosql.diana.mongodb.document.MongoDBDocumentConfiguration;

@ApplicationScoped
public class DocumentCollectionManagerProducer {
	private DocumentConfiguration<MongoDBDocumentCollectionManagerFactory> configuration;
	private DocumentCollectionManagerFactory<MongoDBDocumentCollectionManager> managerFactory;

	@PostConstruct
	public void init() {
		configuration = new MongoDBDocumentConfiguration();
    // Modify this if MongoDB is not on localhost
		Map<String, Object> settings = Collections.singletonMap("mongodb-server-host-1", "localhost:27017"); //$NON-NLS-1$ //$NON-NLS-2$
		managerFactory = configuration.get(Settings.of(settings));
	}

	@Produces
	public DocumentCollectionManager getManager() {
		return managerFactory.get("exampledb"); //$NON-NLS-1$
	}
}

There's a lot there, but fortunately some of it builds on the CDI producer/scope functionality we encountered earlier. What we're doing here is setting up an application-wide bean that produces a configuration object for JNoSQL to use - specifically, using MongoDB. In a real situation, you'd want to externalize the settings in some way, but putting it into the code will do for now. The getManager() method will be used behind the scenes when JNoSQL asks the environment for a document-database manager.

Create the Model

Create another new class in the model package, this time named Person:

package model;

import javax.validation.constraints.Email;
import javax.validation.constraints.NotBlank;
import javax.ws.rs.FormParam;

import org.jnosql.artemis.Column;
import org.jnosql.artemis.Entity;
import org.jnosql.artemis.Id;

@Entity
public class Person {
	@Id("id")
	private long id;
	@Column @FormParam("name") @NotBlank
	private String name;
	@Column @FormParam("emailAddress") @NotBlank @Email
	private String emailAddress;

	public long getId() { return id; }
	public void setId(long id) { this.id = id; }
	public String getName() { return name; }
	public void setName(String name) { this.name = name; }
	public String getEmailAddress() { return emailAddress; }
	public void setEmailAddress(String emailAddress) { this.emailAddress = emailAddress; }
}

This class uses JNoSQL's annotations to define an object that can be stored (@Entity), its unique ID field (@Id), and the fields contained in it (@Column, a name that matches JPA's SQL-based view of the world). You can also see that it includes the JAX-RS and validation annotations from the class we set up when learning about MVC. With the artemis-validation dependency we included, JNoSQL will, like JAX-RS, automatically enforce bean property constraints like this when saving, meaning we don't have to spent so much time dealing with validation logic ourselves.

Whether or not it's a good idea mix the JAX-RS and persistence annotations like this is something I'm not entirely sure about, but it'll work for our purposes.

Create the Repository

Create a new interface (not a class) in the model package named PersonRepository:

package model;

import java.util.List;

import org.jnosql.artemis.Repository;

public interface PersonRepository extends Repository<Person, Long> {
	List<Person> findAll();
}

You may be thinking at this point, as I originally did, that the next step will be to create an implementation class to do the work for this. Nope! This is where some real CDI voodoo comes into play: inside JNoSQL is a bean that produces "proxy" classes on the fly for Repository interfaces and figures out implementations of the methods based on their names, return types, and parameters. It's not magic - there are limits - but in cases like this it'll do what we'd otherwise expect to have to do ourselves.

Back to the PersonController

Return to the PersonController class we created before and rework it to use our newly-minted JNoSQL objects:

package com.example;

import javax.enterprise.context.RequestScoped;
import javax.inject.Inject;
import javax.mvc.Controller;
import javax.mvc.Models;
import javax.validation.Valid;
import javax.ws.rs.BeanParam;
import javax.ws.rs.GET;
import javax.ws.rs.POST;
import javax.ws.rs.Path;

import org.jnosql.artemis.Database;
import org.jnosql.artemis.DatabaseType;

import model.Person;
import model.PersonRepository;

@Path("/people")
@Controller
@RequestScoped
public class PersonController {
	@Inject
	Models models;

	@Inject
	@Database(DatabaseType.DOCUMENT)
	PersonRepository personRepository;

	@GET
	public String home() {
		models.put("people", personRepository.findAll()); //$NON-NLS-1$
		return "person-new.jsp"; //$NON-NLS-1$
	}

	@POST
	public String createPerson(@BeanParam @Valid Person person) {
		if(person.getId() == 0) {
			person.setId(new Random().nextLong());
		}
		personRepository.save(person);

		models.put("person", person); //$NON-NLS-1$
		models.put("people", personRepository.findAll()); //$NON-NLS-1$
		return "person-created.jsp"; //$NON-NLS-1$
	}
}

Add a Person List Tag

Back in the "Deployed Resources" section of the project, create a new directory beneath "WEB-INF" called "tags", and within that create a new file named "personList.tag":

WEB-INF/tags directory

Set the file contents to:

<%@tag description="Displays List&kt;model.Person&gt;" pageEncoding="UTF-8" trimDirectiveWhitespaces="true" %>
<%@attribute name="value" required="true" type="java.util.List" %>
<%@taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>

<h1>People</h1>
<table>
	<thead>
		<tr>
			<th>ID</th>
			<th>Name</th>
			<th>Email Address</th>
		</tr>
	</thead>
	<tbody>
		<c:forEach items="${pageScope.value}" var="person">
		    <tr>
		    	<td><c:out value="${person.id}"/></td>
		    	<td><c:out value="${person.name}"/></td>
		    	<td><c:out value="${person.emailAddress}"/></td>
		    </tr>
		</c:forEach>
	</tbody>
</table>

This is our JSP equivalent of an XPages custom control, though all of the configuration is done inline instead of via XPages's auto-maintained .xsp-config side file.

Update the Person Views

Modify "person-new.jsp":

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<%@taglib prefix="t" tagdir="/WEB-INF/tags" %>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		<h1>Create Person</h1>
		<form method="post" action="people">
			<dl>
				<dt>Name</dt>
				<dd><input name="name" required/></dd>
			</dl>
			<dl>
				<dt>Email Address</dt>
				<dd><input type="email" name="emailAddress" required/></dd>
			</dl>
			<input type="submit" value="Submit"/>
		</form>

		<t:personList value="${people}"/>
	</body>
</html>

Do similarly to "person-created.jsp":

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<%@taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
<%@taglib prefix="t" tagdir="/WEB-INF/tags" %>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		<h1>Created Person</h1>
		<dl>
			<dt>Name</dt>
			<dd><c:out value="${person.name}"/></dd>
		</dl>
		<dl>
			<dt>Email Address</dt>
			<dd><c:out value="${person.emailAddress}"/></dd>
		</dl>

		<t:personList value="${people}"/>
	</body>
</html>

Take It For a Spin

Launch the Liberty server and visit http://localhost:9091/javaeetutorial/resources/people. You should be able to add new entries, with the browser taking care of the client-side validation for you and JNoSQL and JAX-RS handling it on the server side. Best of all, the data should persist!

Updated UI with person listing

If you look at the database in Compass, you'll see entries there as well. JNoSQL mapped the Person class name to the "Person" collection in the database:

Data stored in MongoDB

Next Steps

In the next post, I plan to touch a bit on mixing MVC controller methods with JSON-based REST APIs, to bring these parts together into something that starts to approach a real application.

Update: Troubleshooting Note

One thing I encountered in my fiddling was an intermittent case where the server wouldn't load the app, instead complaining about an unsatisfied provider for the PersonRepository class. If you run into this, make sure you have a "beans.xml" file inside your "webapp/WEB-INF" directory in "Deployed Resources", and set its contents to:

<?xml version="1.0" encoding="UTF-8"?>
<beans bean-discovery-mode="all"
  xmlns="http://xmlns.jcp.org/xml/ns/javaee"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/beans_2_0.xsd"/>

This is the CDI configuration file. Though it's mostly empty, the critical part is bean-discovery-mode="all", which causes it to check all available providers in the classpath.

XPages to Java EE, Part 9: IDE Features Grab Bag

  • Feb 13, 2019

In today's post, I'm going to go over a handful of features that IDEs, particularly Eclipse, bring to the table to improve the development experience. Some of these aren't unique to EE development, but our use of Maven and standardized technology makes them better than their equivalents in XPages development.

Open Declaration

In Eclipse, if you right click on most anything in a Java file, you can choose "Open Declaration" (or press F3 with the text cursor inside it), you can go to the source of whatever it is, if available:

Open Declaration menu item

This also works in Designer, but it's often much more useful here: because Designer ships without source for its JVM or really any of the classes that make up the XPage stack, you tend to be greeted by the white "here's a bunch of bytecode" screen, which is rarely particularly useful.

Since we're working with open-source components and we told Eclipse to download source and Javadoc for Maven artifacts, though, almost everything will have available source, letting you explore what's happening much more easily.

This will also work for your own code, making F3 an extremely-useful method of navigation. While you're there, try out the "Open Type Hierarchy" and "Open Call Hierarchy" options too.

Open Implementation

CDI's technique of using @Inject to inject implementations of interfaces automatically is a great way to abstract away the business of doing a new SomethingImpl() or finding the managed bean. However, sometimes it's good to find out where the objects you're getting are actually coming from, and Eclipse lets you do this by holding Command (probably Control on Windows, if I had to guess) and hovering over an interface name:

Open Implementation menu option

In this menu, "Open Declaration" will take you to the Models interface class file, while "Open Implementation" will take you to the ModelsImpl implementation class.

Note, though, that Eclipse isn't really following CDI logic here - instead, it's just trying to find implementing classes and either opening a single implementation if there's only one or showing a menu to select from multiple. It happens that that's usually the same thing effectively, but it's an important distinction.

IntelliJ is a bit smarter on this point: it will try to figure out all the CDI logic and show a little bean icon on a line with an injection to take you to the object or method providing it:

IntelliJ bean detection

JBoss Tools

To be fair to Eclipse, there is a project to provide a great deal of improved Java EE behavior: JBoss Tools. It comes with a bunch of addins, editors, and configurators meant to make Eclipse much more aware of things like CDI's real logic. I personally have found it pretty janky in practice, but it's been a while since I gave it a proper shot. Your mileage may vary.

JAX-RS Resources

Since JAX-RS is such a critical part of modern Java development, it comes in handy that Eclipse has some specialized knowledge of it. If you expand the "Services" folder in your project, you'll have a "REST" folder that contains all of your declared JAX-RS endpoint classes and their methods:

Eclipse JAX-RS resource listing

You can use this as a general overview of your app's external API (and, when using MVC, its full URL layout) and you can also double-click any of the entries to go to the declaration.

If you get into a situation where you're writing a paired set of a server module and a client module, you can also let Eclipse generate a resource client class for you.

Deployment Descriptor

Within the "Deployment Descriptor" node in your project, Eclipse lists a bunch of EE/Servlet stuff:

Deployment Descriptor node

Historically, this referred specifically to the contents of the web.xml, but it also shows annotated classes as applicable - such as the Listener coming from the Ozark MVC implementation. Depending on how you're constructing your app, this may be more or less useful, but it's definitely good to know it's there.

Up Next

Next time, maybe I'll finally get to talking about users and data. Or maybe I won't! We'll see.



XPages to Java EE, Part 8: IDE Server Integration

  • Feb 12, 2019

I said that the next post was going to be about authentication or databases, but I'm turning that into a filthy lie. Instead, we're going to take a bit of a detour to talk about a couple ways to let the IDE help you out in development. I'll be talking about Eclipse specifically, but I know that at least the paid version of IntelliJ IDEA has similar features. The first feature on the docket is having the IDE manage an app server for you.

Servers

Up until this point, we've been using the TomEE Maven plugin to create and launch a server for us, which is convenient and portable across whatever environment you're working with. However, once you have a couple applications or want to make persistent server configurations outside of the individual app's pom.xml, it makes sense to run a server and deploy the app to it.

This is where Eclipse's "Servers" view comes into play. If the panel isn't currently in your workspace, go to Window -> Show View -> Other... and choose "Servers" under the "Server" category. By default, it'll be stacked with some other tabs, but I like to position this pane in the bottom-right of my IDE:

Eclipse Servers view

The way this view tends to work is that it points either at a local server installation or to a running remote server. We'll want the former, but, sadly, this is where we part ways with TomEE. Though the server is more than capable for our needs, the Eclipse integration (based on base Tomcat) is not, and it hinders its use here. Instead, we'll be switching to my current favorite: Open Liberty. Download the latest build from that page (19.0.0.1 as of this writing) and extract the archive to some location on your system (I like to keep a directory of various app servers).

Next, we'll need to install the Liberty support plugin in Eclipse, which is a fortunately-simple matter. Visit the Liberty in Eclipse download page and drag the "Install" button onto your Eclipse toolbar. Once it loads, click Next and Finish a couple times until it's done, and then let it restart Eclipse.

Once Eclipse restarts, click that "Click this link to create a new server..." link. In the resultant dialog, choose "Liberty Server" under the "IBM" category and give it a descriptive name:

Eclipse's New Server dialog

Click Next > and enter the path where you extracted Open Liberty in the "Path" field:

Server path

Click Next >, leave everything at its default, and click Finish.

Click the twistie next to the newly-created server and double-click the "Server Configuration [server.xml] new server" entry to open the server config editor. If it opens on the "Design" tab, click the "Source" tab to see the XML configuration. Set it to:

<server description="new server">
    <!-- Enable features -->
    <featureManager>
        <feature>javaee-8.0</feature>
        <feature>localConnector-1.0</feature>
    </featureManager>

    <!-- To access this server from a remote client add a host attribute to the following element, e.g. host="*" -->
    <httpEndpoint httpPort="9091" httpsPort="9443" id="defaultHttpEndpoint"/>

    <!-- Automatically expand WAR files and EAR files -->
    <applicationManager autoExpand="true"/>

    <keyStore id="defaultKeyStore" password="testKeystore"/>
</server>



The first difference here from the default is to swap out the jsp-2.3 feature for javaee-8.0. Liberty organizes its capabilities by "features" in order to let you really trim down the runtime if you don't need specific capabilities. For our sake, we want the whole EE shebang available, though. localConnector-1.0 remains, and is what allows Eclipse to control the server.

We also changed the httpPort of the httpEndpoint element to 9091 to match what we've been using via the Maven config. We also added a basic not-exactly-secure keyStore configuration. This would be filled in more if you enable SSL.

Deploying the App

There are several ways to actually get our app onto this server, but the one I've built up a habit of using is to right-click the project, and then select Run As -> Run On Server:

Run on Server

The newly-created server should be selected by default in the resultant dialog, so just click Finish immediately.

The server will churn for a bit and eventually output [AUDIT ] CWWKT0016I: Web application available (default_host): http://localhost:9091/javaeetutorial/. It will also, I note with chagrin, output this:

[ERROR   ] SRVE0283E: Exception caught while initializing context: java.lang.IllegalArgumentException: The controller com.example.HomeController is not a managed CDI bean. Maybe the controller class is missing a scope annotation (e.g. @RequestScoped).
	at org.mvcspec.ozark.servlet.OzarkServletContextListener.failIfNoCdiBean(OzarkServletContextListener.java:76)
	at org.mvcspec.ozark.servlet.OzarkServletContextListener.contextInitialized(OzarkServletContextListener.java:60)
	at com.ibm.ws.webcontainer.webapp.WebApp.notifyServletContextCreated(WebApp.java:2377)
	at [internal classes]

That's because I forgot a step in the setup of MVC controllers yesterday, which is that you're supposed to add one of those annotations to the class too. Fortunately, the examples still work, and we'll fix that omission next time we edit the code.

Most likely, Eclipse will automatically open the app's default page in whatever browser it's configured to use - by default, a browser embedded in Eclipse itself.

Updating the App

In future posts, rather than specifically saying to run the clean install tomee:run Maven goal, I'll just say to run the app - either way should still work. By default, Eclipse will re-deploy the application to Liberty after changes, so you probably won't need to do anything other than refresh the page to see future changes.

Next Up

Next, I think I'm going to cover a grab bag of other features Eclipse has for working with Java EE apps before returning to the dirty business of writing code.



XPages to Java EE, Part 7: MVC

  • Feb 11, 2019

I mentioned in the last post that the rest of this tutorial is going to involve making some technology choices that are less universal than the ones up until this point. While pretty much every new EE app is going to involve CDI and JAX-RS, things will start to diverge once you decide on how you're going to handle authentication, your UI, and your data storage. We're going to dip into the the second one of those today.

Specifically, we'll be choosing the characteristically-dryly-named MVC Spec as the foundation for our interface.

MVC

If you're not familiar with the term "MVC" in a general sense, it stands for Model-View-Controller, and it represents one of the common ways to structure your application to keep the code clean and growable without it turning into a nightmare. There are other ways, and there are some flaws in the design that require band-aid solutions, but in general it remains a very-useful way to write your app. The general idea is that you have three components: the "model" (your data), the "view" (what your user sees), and the "controller" (what connects the two). On the web, this often takes the shape of having controllers pointed to by the "routing" within your application (e.g. /posts/new), which then do the work of fetching the data and binding it to the view.

XPages is ostensibly MVC-based, but that doesn't really play out in reality. The stack and IDE encourage direct mingling of the view and data (the <xp:dominoDocument/> data source and SSJS are the primary culprits here), and the lack of a model framework and the stultifying strictures of the built-in NHTTP routing make it very difficult to do it right even if you try (and lord knows we tried).

The MVC Spec

I've talked a bit about the spec before, and the idea of it is to build a simple-to-write-and-read MVC standard for Java EE, using existing EE technologies for the "view" part. I believe that the spec is heavily based on Spring MVC, though I haven't written any Spring apps.

The main reason I'm such a big fan of this spec is that it builds cleanly on top of JAX-RS, which already provides an excellent skeleton for cleanly-organized apps. JAX-RS already encourages clean, RESTful design for accessing data objects, and MVC builds on that to provide a natural way to display a web UI for non-API clients (which is to say, humans).

One thing to bear in mind with MVC 1.0 is that it's not quite a true Java EE component. It was slated for inclusion in Java EE 8, but Oracle cut it from the list before release. However, the spec has support within the Jakarta EE community and remains a likely candidate for future inclusion. Moreover, because the spec is so small and strongly encourages clean design, I feel that it's worth building upon - even if it disappeared tomorrow, almost all of your code would still work.

Adding to the Project

Since the spec isn't included in the default Java EE 8 spec or with EE servers, we'll need to add explicit dependencies to the pom.xml for the project, for both the spec itself and the reference implementation (currently named "Ozark", but it's going through a rename to "Krazo" for trademark purposes):

<!-- MVC 1.0 -->
<dependency>
  <groupId>javax.mvc</groupId>
  <artifactId>javax.mvc-api</artifactId>
  <version>1.0-pfd</version>
</dependency>
<dependency>
  <groupId>org.mvc-spec.ozark</groupId>
  <artifactId>ozark-core</artifactId>
  <version>1.0.0-m04</version>
</dependency>

Creating the Controller

MVC Controllers are implemented as normal JAX-RS resources with the extra @Controller annotation, and whose methods return an indicator of what view to use. Create a class in the com.example package called HomeController:

package com.example;

import java.time.LocalDateTime;

import javax.inject.Inject;
import javax.mvc.Controller;
import javax.mvc.Models;
import javax.ws.rs.GET;
import javax.ws.rs.Path;

@Path("/")
@Controller
public class HomeController {
	@Inject
	Models models;

	@GET
	public String hello() {
		models.put("hello", "Hello, MVC!"); //$NON-NLS-1$
		models.put("now", LocalDateTime.now()); //$NON-NLS-1$

		return "hello.jsp"; //$NON-NLS-1$
	}
}

The "Models" object is a MVC-provided object that acts sort of like a viewScope: you toss whatever objects you'd like into it and they're available as variables on your page. Despite having an important-sounding name, it's really just a simplified Map.

Creating the View

MVC supports several "templating" technologies, among them JSP and JSF Facelets. However, though it uses JSF technology, it's not meant to be used for a full JSF app with server-side state. From what I can tell, the JSF support is more for those who already have JSF apps to use. Despite XPages's heritage, that doesn't really apply to us. Create a new folder named "views" within the "webapp/WEB-INF" directory in "Deployed Resources" (which is "src/main/webapp" in the filesystem). Then, create a new file and call it "hello.jsp":

hello.xhtml location

Set its contents to:

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		<h1>${hello}</h1>
		<p>I was loaded at ${now}.</p>
	</body>
</html>

Since this still uses CDI, we're still able to use the translation bean we set up earlier, but now we have access to the extra variables the controller set up.

If you do another Maven build with goals "clean install tomee:run" and visit http://localhost:8081/javaeetutorial/resources now, you should be greeted with the expected basic page:

Basic MVC output

Working With a Model

So that's two out of three down; time to simulate some data access. Using a real backing database will be its own large topic, so for now we'll create a simple in-memory object.

Create a new class in the "com.example" package named "PersonController":

package com.example;

import javax.inject.Inject;
import javax.mvc.Controller;
import javax.mvc.Models;
import javax.validation.Valid;
import javax.validation.constraints.NotEmpty;
import javax.ws.rs.BeanParam;
import javax.ws.rs.FormParam;
import javax.ws.rs.GET;
import javax.ws.rs.POST;
import javax.ws.rs.Path;

@Path("/people")
@Controller
public class PersonController {
	public static class FormPerson {
		@FormParam("firstName") @NotEmpty
		private String firstName;
		@FormParam("lastName") @NotEmpty
		private String lastName;

		public String getFirstName() { return firstName; }
		public String getLastName() { return lastName; }
	}


	@Inject
	Models models;

	@GET
	public String home() {
		return "person-new.jsp"; //$NON-NLS-1$
	}

	@POST
	public String createPerson(@BeanParam @Valid FormPerson person) {
		models.put("person", person); //$NON-NLS-1$
		return "person-created.jsp"; //$NON-NLS-1$
	}
}

Next, create a new file in the "WEB-INF/views" directory named "person-new.jsp":

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		<h1>Create Person</h1>
		<form method="post" action="people">
			<dl>
				<dt>First Name</dt>
				<dd><input name="firstName" required/></dd>
			</dl>
			<dl>
				<dt>Last Name</dt>
				<dd><input name="lastName"/></dd>
			</dl>
			<input type="submit" value="Submit"/>
		</form>
	</body>
</html>

Finally, create a second JSP file in the same directory named "person-created.jsp":

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<%@taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		<h1>Created Person</h1>
		<dl>
			<dt>First Name</dt>
			<dd><c:out value="${person.firstName}"/></dd>
		</dl>
		<dl>
			<dt>Last Name</dt>
			<dd><c:out value="${person.lastName}"/></dd>
		</dl>
	</body>
</html>

Now, do another Maven build and visit http://localhost:9091/javaeetutorial/resources/people:

Create Person page

In this screenshot, you can see that the "First Name" field got a red outline because it's marked as required and I entered and then deleted a first name value. Neat!

Anyway, fill in something for "First Name" but not "Last Name", and hit "Submit". You'll be greeted with... nothing! Well, visibly nothing, anyway. You'll have a 400 response in your browser with no content, and you'll see a line like this in your server console:

11-Feb-2019 14:52:55.942 WARNING [http-nio-9091-exec-2] org.apache.cxf.jaxrs.validation.ValidationExceptionMapper.toResponse Value '' of PersonController.createPerson.arg0.lastName: {javax.validation.constraints.NotEmpty.message}

Hey, the server-side validation worked! Down the line, we'll probably add an exception handler to display this type of thing to the user, but, for now, the important part is that invalid data was blocked before it even got to our code.

Go back and enter something for each of the name fields, and then hit "Submit" again. While doing so, bask in the pleasant fact that, because there's no server-side state, you don't need to worry about mangled JSF view state or anything. Once you submit, you should be greeted with the "Created Person" page with your data:

Created Person page

As a nice bonus, because this output page uses the JSTL <c:out/> tag, the values are nicely HTML-escaped, making it a bit more secure than our original Hello World page.

Next Steps

In the next couple posts, we'll cover the ominous topics of authentication and data storage.

XPages to Java EE, Part 6: Dependencies

  • Jan 31, 2019

This is going to be a quick post, but I think it's useful to treat the topic of third-party dependencies on its own because of how much nicer it is with a Maven-based app than an NSF or OSGi plugin.

Historically, we've handled dependencies primarily by downloading a Jar and either plunking it in jvm/lib/ext on the server, stashing it in a Java agent or script library, or importing it into the NSF as a Jar design element for XPages. With OSGi plugins, that remained the simplest way to do it too: just drop the Jar into the plugin and add it to the bundle classpath.

The two big problems with those approaches are that they rely on having just "some file" deployed around with no version management and they also don't include any source. As anyone who's tried to figure out some behavior inside the XPages stack knows, not having the source for your dependencies is a real pain in the ass.

Building a normal Maven (or Gradle) project, though, means dependency management becomes much easier and we get source support "for free".

Eclipse Prep

Before we begin, open your Eclipse preferences and go to the "Maven" category. There, turn on "Download Artifact Sources" and "Download Artifact Javadoc":

Eclipse's Maven preferences

This will cause Eclipse to automatically use Maven's ability to download associated source and Javadoc for dependencies (referred to "artifacts" in Maven parlance). You can do this manually after the fact or via the command line, but it's nice to have it on by default.

Adding the Dependency

For our example, we'll bring in a Markdown processor. Open the project's pom.xml file and set the dependencies block to this:

	<dependencies>
		<dependency>
			<groupId>javax</groupId>
			<artifactId>javaee-api</artifactId>
			<version>8.0</version>
			<scope>provided</scope>
		</dependency>
		<dependency>
			<groupId>com.atlassian.commonmark</groupId>
			<artifactId>commonmark</artifactId>
			<version>0.12.0</version>
		</dependency>
	</dependencies>

Save the file and that's it - Eclipse will automatically fetch the Jar and add it to the project's build path:

Eclipse's Maven Dependencies library

Note that the two dependencies in the pom.xml have a key difference: the Java EE API dependency is marked as <scope>provided</scope> while the new dependency has no specified scope (technically making it compile scoped). This determines the behavior of the .war packager: a "provided" dependency is available while developing, but is not packaged with the application. This is used to indicate that you expect the runtime environment to provide this dependency for you, which a Java EE container does for the EE API. With a default/compile-scoped dependency, the Jar is included in the app's WEB-INF/lib directory, which the container knows to include in the app's runtime class path.

Using the Dependency

This section shouldn't have any surprises: now that you added the dependency, it's available for your app. Create a new class in the com.example package named MarkdownExample with this contents:

package com.example;

import javax.ws.rs.GET;
import javax.ws.rs.Path;
import javax.ws.rs.Produces;
import javax.ws.rs.core.MediaType;

import org.commonmark.node.Node;
import org.commonmark.parser.Parser;
import org.commonmark.renderer.html.HtmlRenderer;

@Path("markdown")
public class MarkdownExample {
	@GET
	@Produces(MediaType.TEXT_HTML)
	public String get() {
		Parser markdown = Parser.builder().build();
		Node parsed = markdown.parse("# Hello\n\nWorld"); //$NON-NLS-1$

		HtmlRenderer markdownHtml = HtmlRenderer.builder().build();
		return markdownHtml.render(parsed);
	}
}

As before, run a Maven Build with the goals clean install tomee:run and then visit http://localhost:9091/javaeetutorial/resources/markdown. If all goes well, you should see the HTML output:

Markdown HTML output

Updating the Dependency

Beyond just automatically bringing in dependencies, Maven gives us a raft of abilities to manage them. Do a Run As -> Maven Build... on the project and this time set the goals to versions:display-dependency-updates This will run for a bit to look up all of your dependencies to find if any are out of date. After running, you should see something like this near the bottom (the versions may differ based on when you do this):

[INFO] The following dependencies in Dependencies have newer versions:
[INFO]   com.atlassian.commonmark:commonmark ................. 0.12.0 -> 0.12.1
[INFO]   javax:javaee-api ..................................... 8.0 -> 8.0.1-b5

You can also have Maven automatically bump the versions in your pom.xml for you, but this demonstrates why I don't like to do that: the javaee-api update is to a beta version, and we have no need to move to that. There's no reason not to update our commonmark dependency, though, and so I like to run this (and the equivalent command to look for Maven plugin updates) periodically.

Next Steps

After these basics, the next steps are going to have to involve making some choices that won't apply as generally as the steps so far. Data storage and user authentication are going to vary greatly from environment to environment, but I'll aim to show the current ways to do those in a mostly-agnostic fashion.

XPages to Java EE, Part 5: Web Pages

  • Jan 24, 2019

Once upon a time, web pages were easy: you'd write some HTML directly or, if you're fancy, use some Server Side Includes or PHP. Now, though, it's a rat's nest of decisions and stacks - fortunately for me, going into the pros and cons of each approach is beyond the scope of this series. Suffice it to say that Java EE can cover your needs whatever approach you take: it can do basic dynamic HTML generation, run server-persisted frameworks like JSF, and work splendidly as a backend for a client JS app thanks to JAX-RS.

For this post, I'm going to stick to some basics: a JSP page pulling in values from a translation resource bundle. This should provide a nice introduction to a couple more core technologies that will come in handy in app development, in particular CDI.

Translation File

Localization and internationalization are huge topics and there are many approaches to take, both in technology and in style within individual technologies. I won't weigh in too much on that in general, but I'll keep it simple here. Using the Java ResourceBundle class, you can use a set of .properties files in your project to provide translations for different locales, as well as a default. Even though almost everything I write ends up US-English-only anyway, I like to have something like this for good practice.

Open the Java Resources node of the tutorial project, right-click on src/main/resources, and choose New -> Other:

For the type, choose "File" under the "General" category:

Set the name of the file to "translation.properties":

In the new file, set the contents to this (or feel free to customize at will):

_lang=en
appTitle=Java EE Tutorial
welcome=Hello, {0}

Index Page

Now, right-click on the project root and choose New -> JSP File:

If you don't see that entry in the New menu, pick Other... and do a search in that dialog for "JSP".

Name this file "index.jsp" and hit Finish:

If you hit Next >, you'll have the option to pick from some pre-made templates, which is good to know about, but we don't need it now.

Replace the new file's contents with this:

<%@page contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" trimDirectiveWhitespaces="true"%>
<!DOCTYPE html>
<html lang="${translation._lang}">
	<head>
		<title>${translation.appTitle}</title>
	</head>
	<body>
		${messages.format("welcome", param.name)}
	</body>
</html>

Unlike with XPages, we're starting with bare bones here: no HTML will show up on the page unless you explicitly put it in here, either via HTML you write or via programmatic tags you bring in. The binding language, though, should be familiar: that's EL 3, which is (among other things) the current form of the expression language found in XPages. Since we're working with a JSP page, there's no such thing as a "run-time binding", so everything is the ${}-style "on page load" format. The language is also fancier nowadays, and you can see a method expression at work.

Translation Bean

So now we have the backing translation file and the front-end page using it, but we're missing the glue that connects the two. For that, we'll create some CDI managed beans.

Create a new Java class in the bean package named TranslationBean and set its contents to this:

package bean;

import java.text.MessageFormat;
import java.util.ResourceBundle;

import javax.enterprise.context.RequestScoped;
import javax.enterprise.inject.Produces;
import javax.inject.Inject;
import javax.inject.Named;
import javax.servlet.http.HttpServletRequest;

@RequestScoped
public class TranslationBean {
	@Inject
	HttpServletRequest request;

	@Produces @Named("translation")
	public ResourceBundle getTranslation() {
		return ResourceBundle.getBundle("translation", request.getLocale()); //$NON-NLS-1$
	}

	@RequestScoped
	@Named("messages")
	public static class Messages {
		@Inject
		HttpServletRequest request;
		@Inject @Named("translation")
		ResourceBundle translation;

		public String format(String key, Object... params) {
			String message = translation.getString(key);
			return MessageFormat.format(message, params);
		}
	}
}

There are a few weird bits going on here, but some of them are direct analogues to what we do in XPages.

For starters, the @RequestScoped annotation is exactly what you might think: it marks the class as being a request-scoped managed bean, and the semantics of this are the same as in XPages, just without having to add an explicit definition like in faces-config.xml. This is paired with @Named("messages"), which defines the name of the bean as used by the JSP page.

Next up is the @Inject annotation, which really dips into the magic going behind the scenes. In a Java EE app, CDI acts as a sort of general object-management layer, and it picks up on annotations like these and sets the values of object properties based on providers. In the case of HttpServletRequest, the app has implicit knowledge of the current request, and so can inject it there - this is kind of similar to how an XPages app always has a session object implicitly available. This is also similar to "managed properties" in JSF/XPages, though it's a rare XPages app that uses those.

The part that's entirely new is the @Produces annotation. This tells CDI that a given method can churn out an object matching a specific characteristic, and we use that here for getTranslation(). Because ResourceBundle on its own doesn't have an implicit instance like HttpServletRequest does, we declare the method as producing a ResourceBundle specifically with the name "translation". This name is used both on the JSP page as a normal managed-bean name and also within the inner Messages class, which asks for the named ResourceBundle as its own property. There's actually a whole world of different qualifiers and matching patterns that can apply here, and you can also have implementation classes that are actually proxy classes created on the fly. We may deal with those eventually, but not here.

Loading It Up

As before, run the application by executing a Maven build with the goals "install tomee:run". Once it's done, you should be able to go to http://localhost:9091/javaeetutorial/?name=World and be greeted with this visual splendor:

The HTML will be pleasantly sparse:

<!DOCTYPE html>
<html lang="en">
	<head>
		<title>Java EE Tutorial</title>
	</head>
	<body>
		Hello, World</body>
</html>

An actual application page would naturally get much more complex (for one, it shouldn't have the giant script-injection hole this one has via the direct inclusion of the query parameter), but you get the idea.

Next Steps

Next, I think that I'll show a quick example of bringing in a third-party dependency. The process for that is pretty quick, but I think it will be useful to show the mechanics and use it as an example of something that is a couple steps easier outside of Domino.

There are also a number of big topics remaining: user security, database access, and so forth. I don't know how deep I'll go into each of those, since the implementations vary so much in practice, but I think it'll be useful to at least have an example to start with.

XPages to Java EE, Part 4: Application Servers

  • Jan 23, 2019

I mentioned in the terminology post that one of the new things to get used to in Java EE is the concept of a "Servlet Container" or "Application Server", and I think that this concept is worth a bit of going in to.

In a general sense, we've been working with this concept for a good while now: Domino is an application server in several senses, and (for the most part) the NSFs are the applications it houses. It blurs the lines in a couple ways by virtue of NSFs also being data stores, but an XPages application is a pretty direct match for a .war file deployed to an application server, code-wise.

The Options

So, conceptually we have a match, but a remaining huge different is choice. If you want to run an XPages app, you (more or less) just use Domino. For Servlet apps, there are a lot of options. And, importantly, there are two main types: basic servlet containers and full-fledged EE application servers.

The primary normal servlet container you're likely to have heard of is Apache Tomcat. It's very commonly used as an embedded server with Java web apps like Artifactory. Jetty is the other common one to know about, and it serves a similar role, and apparently has found its place as embedded plumbing inside complicated systems.

Those server won't inherently run a Java EE application, however. For example - if you try to deploy the app from the previous entry to Tomcat, it won't load up the JAX-RS services, since the undergirding infrastructure won't be there to pick up on them. You can, though, kind of piece together your own app server on top of Tomcat: if you include a JAX-RS implementation as a Maven dependency, you could make it work. This is a nice ability for if you only one to use one technology or are trying out something bleeding-edge that hasn't made it into a full server yet.

We'll largely be working with full EE servers, though - it's just more convenient to have these things provided by the container rather than having to pick from the buffet of implementations and provide connective glue to make them work together. The ones you're most likely to run into here (unless you fork over tons of cash for a commercial one) are GlassFish (the reference implementation, on its way to Eclipse), its cousin Payara, TomEE (conceptually Tomcat with bundled EE addons), WildFly, and Open Liberty (which I'm partial to).

Choosing

Hypothetically, all of the EE servers are mutually compatible when it comes to the specs, and this plays out well for the most part. If you write a JAX-RS-based application like our example, it doesn't matter too much if you're running on WildFly (which uses RESTEasy for JAX-RS) or Liberty (which uses Apache CXF): neither needs additional configuration and they'll both do the same thing.

As usual, things get fiddly around the edges. For example, file handling in JAX-RS has historically been something of a mess, with each implementation having their own custom extension to the standard. Sometimes, it's more subtle: when working on my blog app, I discovered that Liberty serves up text/html responses from JAX-RS with a header specifying ISO-8859-1 encoding, leading me to write a filter class to override this.

The larger your deployment, the more you'll care about the differences, too. Each server has different mechanisms for management/administration, clustering, and so forth. If you're in a situation where you or your company has already thrown in with one, you may as well stick with that, or pick one as closely related to what you do as possible. That's one of the reasons I've been using Liberty so much: since it has a common ancestry with the XPages runtime, some bits are familiar. Otherwise, unless you already have a business relationship with one of the commercial vendors, you can just pick whichever one suits your fancy.

Next Steps

I think that the next post will dive back into some actual code, specifically the pretty-important topic of actually serving up web pages.

XPages to Java EE, Part 3: Hello, World

  • Jan 21, 2019

I expect that I'll have some more theory and explanation to get to in future posts, but I think it will be useful to run through a quick example project. Unlike with my XPages/OSGi examples, there won't be anything in this one that you wouldn't find in any old Java EE tutorial - indeed, I'll be piggybacking on some existing ones to speed things along.

Eclipse Setup

Strictly speaking, none of this tutorial requires Eclipse, so you can feel free to use IntelliJ (or the command line, or whatever), but most of us probably have Eclipse around at this point. The main thing you'll need is to ensure that you have the "Java EE"/"Enterprise Java" variant of Eclipse from their downloads page. That's been the go-to one for XPages library development all along, so you may already have it.

Additionally, you'll need at least Java 8 installed and configured. I think that recent Eclipse versions require that, so you should be fine there too.

Creating the Project

To create the project, go to File -> New -> Other..., and then chose "Maven Project":

Click Next >, and leave the following page at its defaults:

The next page asks about the "archetype" to use. In Maven terminology, an archetype is a template project that comes pre-populated with configuration information for a given project type. In our case, we'll add an archetype from outside the list - specifically, a quickstart project from Adam Bien, who is a great resource for Java EE knowledge.

To do this, click on Add Archetype... and fill in the Group Id "com.airhacks", the Artifact Id "javaee8-essentials-archetype", and Version "0.0.1":

Leave "Repository URL" blank, click OK, and then select the newly-added archetype on the original page:

After that, click Next >, which will bring you to a screen to provide Maven artifact details. Set the Group Name to "com.example" and the Artifact ID to "javaeetutorial". Leave the other fields as they are.

After that, click Finish. If all goes well, Eclipse will create the project and gussy it up with its Java EE support, resulting in a project that looks like this:

Adding a JAX-RS Resource

At this point, you have a Java EE project primed for use, but it doesn't really do anything yet. For a modern Java app, your most likely starting point is going to be JAX-RS, so we'll create an example service there. If you've created a Wink service for Domino before, this will be familiar, but slightly easier now that so much configuration is implied.

To start, expand the "Java Resources" node of the project, right-click the "src/main/resources" entry, and choose New -> Class:

Set the package to "com.example" and the class name to "HelloWorldResource". Leave everything else as-is and hit Finish:

Set the contents of the class to the following:

package com.example;

import javax.json.Json;
import javax.ws.rs.GET;
import javax.ws.rs.Path;
import javax.ws.rs.Produces;
import javax.ws.rs.QueryParam;
import javax.ws.rs.core.MediaType;

@Path("helloworld")
public class HelloWorldResource {
	@GET
	@Produces(MediaType.APPLICATION_JSON)
	public String hello(@QueryParam("name") String name) {
		return Json.createObjectBuilder()
			.add("message", "Hello, " + name) //$NON-NLS-1$ //$NON-NLS-2$
			.build()
			.toString();
	}
}

This is pretty similar to the previous series's REST resource, but it removes the Domino references and switches from IBM Commons's JSON implementation to the relatively-new JSON-P standard. JSON-P and its companion spec JSON-B aim to bring some consistency to the world of JSON handling in Java, though their usage is far behind other implementations like Gson or Jackson. They're part of the Java EE spec, though, so they come "for free" with our project, and they're pretty good.

Running the App

At this point, we have enough to build a .war file out of the app and deploy it to a suitable app server, and that can be done a number of ways. The route we'll take for now is the Maven-focused route: providing enough configuration in the project's pom.xml to run on a chosen app server, in this case TomEE, the Java EE variant of Tomcat.

To accomplish this, open the project's pom.xml file and set its contents to:

<project xmlns="http://maven.apache.org/POM/4.0.0"
	xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<groupId>com.example</groupId>
	<artifactId>javaeetutorial</artifactId>
	<version>0.0.1-SNAPSHOT</version>
	<packaging>war</packaging>
	<dependencies>
		<dependency>
			<groupId>javax</groupId>
			<artifactId>javaee-api</artifactId>
			<version>8.0</version>
			<scope>provided</scope>
		</dependency>
	</dependencies>
	<build>
		<finalName>javaeetutorial</finalName>
		<plugins>
			<plugin>
				<groupId>org.apache.tomee.maven</groupId>
				<artifactId>tomee-maven-plugin</artifactId>
				<version>8.0.0-M1</version>
				<configuration>
					<tomeeVersion>8.0.0-M1</tomeeVersion>
					<tomeeClassifier>plus</tomeeClassifier>
					<tomeeHttpPort>9091</tomeeHttpPort>
				</configuration>
			</plugin>
		</plugins>
	</build>
	<properties>
		<maven.compiler.source>1.8</maven.compiler.source>
		<maven.compiler.target>1.8</maven.compiler.target>
		<failOnMissingWebXml>false</failOnMissingWebXml>
	</properties>
</project>

Like before, there's a bit of "just paste in the XML" to Maven, but fortunately it's a much smaller bite than when we were dealing with OSGi. The addition here is to add the tomee-maven-plugin pointing to the current milestone release as of this writing.

Once you've saved this file, right-click the project in Eclipse and choose Run As -> Maven Build... (with the ellipsis):

In the resulting dialog, enter "install tomee:run" in the "Goals" field:

Click Run and let the build proceed. It will churn a bit, first compiling the project and then downloading the necessary components to run the server.

If all goes well, you should see a lot of chatter in Eclipse's output finishing (most likely) with a line about "Server startup". You should then be able to visit http://localhost:9091/javaeetutorial/resources/helloworld?name=World and see JSON output from the service:

Next Steps

At this point, you should have a working Java EE application using possibly the most important part of the stack. From here, we'll enter into the worlds of data storage, managed beans, and front-end UI toolkits.
